Influence of diaphragm stiffness on distortional behavior of composite box girder with corrugated steel webs
-
摘要:
为研究横隔板刚度和横隔板数量对波形钢腹板组合箱梁畸变效应的影响，提出了一种可同时考虑横隔板刚度和剪切变形影响的畸变梁单元(B2D-CSW)；基于广义坐标法，建立了波形钢腹板组合箱形截面畸变翘曲位移表达式，修正了畸变剪力对畸变剪切变形的影响，理论推导了畸变剪力与畸变双力矩的物理关系；利用横隔板与箱形截面之间的位移协调条件，建立了不同类型横隔板的变形表达式及其与畸变角的几何关系，揭示了其抵抗畸变变形的工作机理；基于能量变分法，推导了考虑畸变剪切变形影响的波形钢腹板组合箱梁控制微分方程，选用齐次解构造了广义位移的插值函数；结合有限单元法，开发了考虑畸变剪切变形影响的两节点四自由度畸变梁单元，并推导了考虑横隔板刚度影响的单元的刚度矩阵和等效结点荷载向量；通过算例分析，验证了B2D-CSW梁单元的计算精度与广泛适用性。研究结果表明：与实体有限元模型相比，B2D-CSW梁单元模型仅需少量单元即可准确预测不同横隔板刚度和数量条件下波形钢腹板组合箱梁的畸变响应，显著提升了建模与计算效率；分析表明，横隔板的抗畸变刚度对波形钢腹板组合箱梁的畸变变形具有显著的弹性约束作用，随着横隔板刚度或数量达到临界阈值，其对主梁畸变变形的抑制作用趋于稳定。提出的B2D-CSW梁单元为波形钢腹板PC组合连续箱梁桥横隔板的设计与分析提供了可靠的计算方法。
Abstract:To investigate the influence of diaphragm stiffness and number on the distortional behavior of composite box girders with corrugated steel webs (CSWs), a distortional beam element (B2D-CSW) that incorporates both diaphragm stiffness and shear deformation effects was developed. Based on the generalized coordinate method, expressions for distortional warping displacement in composite box sections with CSWs were formulated, incorporating the influence of distortional shear force on shear deformation. The physical relationship between distortional shear force and distortional bimoment was derived theoretically. By enforcing displacement compatibility between diaphragms and the composite box section, deformation expressions for different diaphragm types and their geometric relationships with the distortion angle were established, thus revealing their mechanism for resisting distortional deformation. Using the energy variational method, governing differential equations for composite box girders with CSWs that account for distortional shear deformation were derived, and interpolation functions for generalized displacements were constructed based on homogeneous solutions. Based on the finite element method, a two-node, four-degree-of-freedom distortional beam element considering distortional shear deformation was developed, and the stiffness matrix and equivalent nodal load vector considering diaphragm stiffness were derived. Through numerical examples, the computational accuracy and wide applicability of the proposed B2D-CSW beam element were verified. The results indicate that, compared with solid finite element models, the B2D-CSW beam element can accurately predict the distortional response of composite box girders with CSWs under varying diaphragm stiffness and number of diaphragms, using only a small number of elements and thus significantly improving modeling and computational efficiency. The analysis shows that the anti-distortional stiffness of diaphragms provides significant elastic restraint on the distortional deformation of composite box girders with CSWs. As the diaphragm stiffness or number reaches a critical threshold, the restraining effect on the distortional deformation of the main girder tends to stabilize. The proposed B2D-CSW beam element provides a reliable computational method for the design and analysis of diaphragms in continuous prestressed concrete (PC) composite box girder bridges with CSWs.
-
图 4 波形钢腹板组合箱形截面荷载分解示意
Figure 4. Schematic of load decomposition for composite box section with CSWs
图 10 简支波形钢腹板组合箱梁(单位：cm)
Figure 10. Simply supported composite box girder with CSWs (unit: cm)
s
图 11 简支波形钢腹板组合箱梁的有限元模型
Figure 11. Finite element model of simply supported box girder with CSWs
图 14 横隔板刚度对波形钢腹板组合箱梁畸变翘曲应力的影响
Figure 14. Influence of diaphragm stiffness on distortional warping stress in composite box girders with CSWs
图 16 横隔板数量对波形钢腹板组合箱梁畸变翘曲应力的影响
Figure 16. Influence of diaphragm quantity on distortional warping stress in composite box girders with CSWs
图 17 某变截面波形钢腹板PC组合连续箱梁桥(单位：m)
Figure 17. Non-prismatic PC continuous composite box girder bridge with CSWs (unit: m)
表 1 横隔板刚度对跨中截面畸变翘曲应力的影响
Table 1. Influence of diaphragm stiffness on distortional warping stress at mid-span section
MPa 测点 不同横隔板厚度(mm)的翘曲应力 0 1 2 5 8 14 20 B 1.01 0.84 0.77 0.69 0.66 0.64 0.63 D 0.22 0.18 0.17 0.15 0.14 0.14 0.14
下载: 导出CSV
表 2 横隔板数量对跨中截面畸变翘曲应力的影响
Table 2. Influence of diaphragm quantity on distortional warping stress at mid-span section
MPa 测点 不同横隔板数量的翘曲应力 0 1 2 4 B 1.01 0.61 0.53 0.51 D 0.22 0.13 0.12 0.11
下载: 导出CSV
-
[1] MO Y L, JENG C H, KRAWINKLER H. Experimental and analytical studies of innovative prestressed concrete box-girder bridges[J]. Materials and Structures, 2003, 36(2): 99-107. doi: 10.1007/BF02479523 [2] HE J, LIU Y Q, CHEN A R, et al. Mechanical behavior and analysis of composite bridges with corrugated steel webs: State-of-the-art[J]. International Journal of Steel Structures, 2012, 12(3): 321-338. doi: 10.1007/s13296-012-3003-9 [3] 聂建国, 陶慕轩, 吴丽丽, 等. 钢-混凝土组合结构桥梁研究新进展[J]. 土木工程学报, 2012, 45(6): 110-122.NIE Jian-guo, TAO Mu-xuan, WU Li-li, et al. Advances of research on steel-concrete composite bridges[J]. China Civil Engineering Journal, 2012, 45(6): 110-122. [4] 董桔灿, 陈宜言, BRISEGHELLA Bruno, 等. 波形钢腹板-双管弦杆-混凝土板组合连续箱梁受弯性能[J]. 交通运输工程学报, 2016, 16(3): 35-45.DONG Jie-can, CHEN Yi-yan, BRISEGHELLA Bruno, et al. Flexural behaviors of composite continuous box-girder with corrugated steel webs, double concrete filled steel tubular chords and concrete slabs[J]. Journal of Traffic and Trans-portation Engineering, 2016, 16(3): 35-45. [5] 陈康明, 黄汉辉, 吴庆雄, 等. 波形钢腹板-钢管混凝土桁式弦杆组合梁桥疲劳性能[J]. 交通运输工程学报, 2022, 22(5): 200-216. doi: 10.19818/j.cnki.1671-1637.2022.05.012 CHEN Kang-ming, HUANG Han-hui, WU Qing-xiong, et al. Fatigue performance of composite girder bridge with corrugated steel webs-concrete filled steel tubular truss chords[J]. Journal of Traffic and Transportation Engineer-ing, 2022, 22(5): 200-216. doi: 10.19818/j.cnki.1671-1637.2022.05.012 [6] 李宏江, 叶见曙, 万水, 等. 波形腹板箱梁的扭转与畸变分析及试验研究[J]. 桥梁建设, 2003, 33(6): 1-4.LI Hong-jiang, YE Jian-shu, WAN Shui, et al. Analysis and experimental study of torsion and distortion of box girder with corrugated steel webs[J]. Bridge Construction, 2003, 33(6): 1-4. [7] 李宏江, 叶见曙, 万水, 等. 波形钢腹板箱梁偏载下的力学性能[J]. 交通运输工程学报, 2004, 4(2): 23-26. http://transport.chd.edu.cn/article/id/200402006LI Hong-jiang, YE Jian-shu, WAN Shui, et al. Mechanical performances of box girder with corrugated steel webs under eccentric loading[J]. Journal of Traffic and Transportation Engineering, 2004, 4(2): 23-26. http://transport.chd.edu.cn/article/id/200402006 [8] 李宏江. 波形钢腹板预应力混凝土组合箱梁扭转与畸变研究进展[J]. 建筑结构学报, 2017, 38(7): 59-67.LI Hong-jiang. Review on torsion and distortion in prestressed concrete box girders with corrugated steel webs[J]. Journal of Building Structures, 2017, 38(7): 59-67. [9] 项海帆. 高等桥梁结构理论[M]. 北京: 人民交通出版社, 2013.XIANG Hai-fan. Advanced theory of bridge structures[M]. Beijing: China Communications Press, 2013. [10] 马磊, 万水, 蒋正文. 单箱双室波形钢腹板箱梁扭转与畸变性能研究[J]. 中国公路学报, 2016, 29(10): 77-85.MA Lei, WAN Shui, JIANG Zheng-wen. Research on torsion and distortion performance of single box double-cell girder with corrugated steel webs[J]. China Journal of High-way and Transport, 2016, 29(10): 77-85. [11] 郭金琼, 房贞政, 郑振. 箱形梁设计理论[M]. 北京: 人民交通出版社, 2008.GUO Jin-qiong, FANG Zhen-zheng, ZHENG Zhen. Design theory of box girder[M]. Beijing: China Communications Press, 2008. [12] 杨丙文, 黎雅乐, 万水, 等. 波形钢腹板箱梁畸变应力分析[J]. 东南大学学报(自然科学版), 2011, 41(5): 1065-1069.YANG Bing-wen, LI Ya-le, WAN Shui, et al. Stress analysis of box girders with corrugate steel webs under distorsion[J]. Journal of Southeast University (Natural Science Edition), 2011, 41(5): 1065-1069. [13] LI L F, ZHOU C, WANG L H. Distortion analysis of non-prismatic composite box girders with corrugated steel webs[J]. Journal of Constructional Steel Research, 2018, 147: 74-86. doi: 10.1016/j.jcsr.2018.03.030 [14] 李立峰, 周聪, 王连华, 等. 基于纽玛克法的变截面波形钢腹板组合箱梁畸变效应分析[J]. 中国公路学报, 2018, 31(6): 217-226.LI Li-feng, ZHOU Cong, WANG Lian-hua, et al. Analysis on distortion effect of non-prismatic composite box girders with corrugated steel webs based on Newmark method[J]. China Journal of Highway and Transport, 2018, 31(6): 217-226. [15] 李运生, 马瑞泽, 张德莹, 等. 隔板式曲线组合梁施工阶段开口薄壁钢梁受力特性研究[J]. 铁道学报, 2014, 36(9): 99-104.LI Yun-sheng, MA Rui-ze, ZHANG De-ying, et al. Research on stressed behavior of open thin-walled steel girders of curved composite beams stiffened by diaphragms in construc-tion stage[J]. Journal of the China Railway Society, 2014, 36(9): 99-104. [16] REN Y Z, CHENG W M, WANG Y Q, et al. Distortional analysis of simply supported box girders with inner diaph-ragms considering shear deformation of diaphragms using initial parameter method[J]. Engineering Structures, 2017, 145: 44-59. doi: 10.1016/j.engstruct.2017.05.004 [17] REN Y Z, CHENG W M, WANG Y Q, et al. Analysis of the distortion of cantilever box girder with inner flexible diaphragms using initial parameter method[J]. Thin-Walled Structures, 2017, 117: 140-154. doi: 10.1016/j.tws.2017.04.010 [18] 张元海, 刘泽翔, 周福成. 考虑横隔板变形影响的薄壁箱梁畸变分析[J]. 东南大学学报(自然科学版), 2024, 54(6): 1456-1463.ZHANG Yuan-hai, LIU Ze-xiang, ZHOU Fu-cheng. Analysis on distortion of thin-walled box girders considering defor-mation of diaphragms[J]. Journal of Southeast University (Natural Science Edition), 2024, 54(6): 1456-1463. [19] 张元海. 设置跨内横隔板的箱形梁畸变效应分析[J]. 土木工程学报, 2021, 54(11): 91-98.ZHANG Yuan-hai. Analysis on distortion effect of box girders with inner-span diaphragms[J]. China Civil Engi-neering Journal, 2021, 54(11): 91-98. [20] ZHANG Y L, WANG C, ZHANG X, et al. Exact distor-tional behaviour of single-box multicell curved composite box girders with corrugated steel webs in the elastic stage[J]. Engineering Structures, 2023, 297: 116961. doi: 10.1016/j.engstruct.2023.116961 [21] 李夏元, 陈建兵, 陈洪兵, 等. 扭转荷载作用下考虑横隔板刚度影响的一种新型箱梁单元[J/OL]. 工程力学, 2025, https://kns.cnki.net/KCMS/detail/detail.aspxfilename=GCLX2025041800H&dbname=CJFD&dbcode=CJFQ .LI Xia-yuan, CHEN Jian-bing, CHEN Hong-bing, et al. A new box girder element considering the influence of diaphragm stiffness under torsional load[J/OL]. Engineering Mechanics, 2025,https://kns.cnki.net/KCMS/detail/detail.aspxfilename=GCLX2025041800H&dbname=CJFD&dbcode=CJFQ .[22] PARK N H, CHOI Y J, YI G S, et al. Distortional analysis of steel box girders[J]. Steel Structures, 2002, 2: 51-58. doi: 10.12989/scs.2002.2.1.051 [23] PARK N H, CHOI S, KANG Y J. Exact distortional beha-vior and practical distortional analysis of multicell box girders using an expanded method[J]. Computers & Structures, 2005, 83(19/20): 1607-1626. [24] PARK N H, KANG Y J, KIM H J. An independent distor-tional analysis method of thin-walled multicell box girders[J]. Structural Engineering and Mechanics, 2005, 21(3): 275-293. doi: 10.12989/sem.2005.21.3.275 [25] PARK N H, LIM N H, KANG Y J. A consideration on intermediate diaphragm spacing in steel box girder bridges with a doubly symmetric section[J]. Engineering Structures, 2003, 25(13): 1665-1674. doi: 10.1016/S0141-0296(03)00145-7 [26] PARK N H, CHOI Y J, KANG Y J. Spacing of intermediate diaphragms in horizontally curved steel box girder bridges[J]. Finite Elements in Analysis and Design, 2005, 41(9/10): 925-943. [27] LEE J, LEE K, CHOI J, et al. Intermediate diaphragm spacing for single-cell rectangular steel box girder bridges considering aspect-ratio[J]. Journal of Constructional Steel Research, 2020, 168: 105877. doi: 10.1016/j.jcsr.2019.105877 [28] LEE J, KIM S, KANG Y J. Effect of cross-sectional rigidity on intermediate diaphragm spacing of steel-box girder bridges[J]. Journal of Constructional Steel Research, 2022, 188: 107006. doi: 10.1016/j.jcsr.2021.107006 [29] 李夏元, 万水, 付理想, 等. 一种考虑波形钢腹板等效剪切变形自由度的新型箱梁单元[J]. 交通运输工程学报, 2025, 25(5): 385-398. doi: 10.19818/j.cnki.1671-1637.2025.05.025 LI Xia-yuan, WAN Shui, FU Li-xiang, et al. A novel box girder beam element considering equivalent shear deformation freedom of corrugated steel webs[J]. Journal of Traffic and Transportation Engineering, 2025, 25(5): 385-398. doi: 10.19818/j.cnki.1671-1637.2025.05.025 [30] ZHOU M, LIU Z, ZHANG J D, et al. Equivalent compu-tational models and deflection calculation methods of box girders with corrugated steel webs[J]. Engineering Struc-tures, 2016, 127: 615-634. doi: 10.1016/j.engstruct.2016.08.047 [31] JOHNSON R P, CAFOLLA J, BERNARD C. Corrugated webs in plate girders for bridges[J]. Proceedings of the Institution of Civil Engineers-Structures and Buildings, 1997, 122(2): 157-164. doi: 10.1680/istbu.1997.29305 [32] LI X Y, LI L F, ZHOU M, et al. Refined beam finite element model for thin-walled multi-cell box girders considering distortion and secondary distortional moment deformation effect[J]. Engineering Structures, 2024, 298: 117042. doi: 10.1016/j.engstruct.2023.117042 -
