Exact finite element method for time-dependent analysis of steel-concrete composite beam considering shear deformation
-
摘要:
为了改善传统位移型有限元方法在分析钢-混组合梁长期力学行为时易产生的曲率闭锁问题，提高计算精度和效率，提出了一种同时考虑双层梁界面滑移效应、梁层剪切变形以及混凝土收缩与徐变影响的钢-混组合梁精确有限元法。基于弹性力学基本方程，结合混凝土线性黏弹性徐变本构模型，推导得到了组合梁单元的控制微分方程并进行了解析求解；采用直接刚度法进一步推导得到了组合梁的精确单元刚度矩阵和等效荷载矩阵，并开发了相应的数值计算程序；通过3个典型算例对所提出的方法进行了验证，并开展了参数分析。分析结果表明：提出的有限元法在同时考虑梁层剪切变形和界面滑移影响的情况下，能够准确预测钢-混组合梁的时变力学响应，即使在单元划分数量较少、收缩与徐变分析时间步数较小的条件下，仍可获得较高精度的计算结果；与解析法相比，365 d的挠度误差不超过3.2%，但计算效率和通用性大大提升；与不考虑剪切效应的有限元法相比，误差减小了10%以上。该方法可为钢-混组合梁长期性能分析及工程设计提供一种高效、可靠的计算手段。
Abstract:To overcome curvature locking in conventional displacement-based finite element methods for analyzing the long-term mechanical behavior of steel-concrete composite beams, and to improve computational accuracy and efficiency, an exact finite element method that accounts for interfacial slip between the two beam layers, shear deformation of beam layers, and the effects of concrete shrinkage and creep was proposed. Based on the fundamental equations of elasticity and a linear viscoelastic constitutive model for concrete creep, the governing differential equations for the composite beam element were derived and solved analytically. The exact element stiffness matrix and equivalent load matrix were formulated using the direct stiffness method, and a corresponding numerical program was developed. The proposed method was validated using three representative examples, followed by a parametric study. The results indicate that the proposed finite element method can accurately predict the time-dependent mechanical response of steel-concrete composite beams while accounting for both shear deformation and interfacial slip. High accuracy can still be achieved with a relatively coarse mesh and a limited number of time steps in shrinkage and creep analysis. Compared with the analytical solution, the error in deflection at 365 d is less than 3.2%, while the computational efficiency and applicability are significantly improved. In comparison with a finite element method that neglects shear deformation, the proposed method reduces the error by more than 10%. The proposed method therefore provides an efficient and reliable computational tool for the long-term performance analysis and engineering design of steel-concrete composite beams.
-
图 1 钢-混组合梁微段受力状态
Figure 1. Stress state of an infinitesimal segment of a steel-concrete composite beam
图 2 钢-混组合梁微段变形
Figure 2. Deformation of an infinitesimal segment of a steel-concrete composite beam
图 3 组合梁单元节点力与节点位移
Figure 3. Nodal forces and nodal displacements of composite beam element
图 10 承受均布荷载与集中荷载的组合梁（单位：mm）
Figure 10. Composite beam subjected to uniformly distributed and concentrated loads (unit: mm)
图 11 时变影响下跨中挠度与跨高比关系
Figure 11. Relationship between mid-span deflection and L/H under time-dependent effects
图 12 时变影响下界面端部滑移与跨高比关系
Figure 12. Relationship between interface end slip and L/H under time-dependent effects
图 13 时变影响下跨中挠度与剪力连接刚度关系
Figure 13. Relationship between mid-span deflection and shear connection stiffness under time-dependent effects
表 1 不同时期梁跨中挠度
Table 1. Mid-span deflection at different time stages
mm 来源 瞬时 30 d 50年 本文 -21.86 -23.09 -31.26 文献[37] -21.33 -22.62 -30.80
下载: 导出CSV
表 2 不同单元数划分下计算结果对比
Table 2. Comparison of calculation results under different element mesh divisions
mm 单元数 瞬时 30 d 50年 2 -21.859 333 3 -23.087 610 7 -31.264 224 4 4 -21.859 333 3 -23.087 610 7 -31.264 224 4 6 -21.859 333 3 -23.087 610 7 -31.264 224 4 10 -21.859 333 3 -23.087 610 7 -31.264 224 4 20 -21.859 333 3 -23.087 610 7 -31.264 224 4
下载: 导出CSV
表 3 不同时期计算结果对比
Table 3. Comparison of calculation results at different time stages
mm 步数 30 d 2年 10年 50年 5 -23.087 61 -29.024 99 -30.730 55 -31.264 22 7 -23.087 61 -29.009 82 -30.724 32 -31.261 96 9 -23.087 61 -28.999 37 -30.712 22 -31.261 35 11 -23.087 61 -28.997 30 -30.652 70 -31.235 32
下载: 导出CSV
表 5 L/H=3时跨中挠度以及端部滑移值
Table 5. Mid-span deflections and end slips at L/H = 3
mm 时期 跨中挠度 端部滑移 计算值 参考值 计算值 参考值 瞬时 0.261 88 0.203 55 0.100 68 0.100 56 31 d 0.323 02 0.250 35 0.127 01 0.124 88 500 d 0.515 93 0.419 26 0.226 21 0.218 09 25 550 d 0.570 57 0.467 58 0.255 29 0.245 01
下载: 导出CSV
表 6 L/H=12时跨中挠度以及端部滑移值
Table 6. Mid-span deflections and end slips at L/H = 12
mm 时期 跨中挠度 端部滑移 计算值 参考值 计算值 参考值 瞬时 15.027 6 14.652 2 1.884 73 1.882 48 31 d 17.856 7 17.381 7 2.254 20 2.243 84 500 d 24.730 1 23.945 3 3.205 25 3.157 74 25 550 d 26.532 3 25.651 0 3.458 21 3.398 17
下载: 导出CSV
表 7 不同时期及跨高比下跨中挠度计算值与参考值之比
Table 7. Ratios of calculated value to reference value of mid-span deflection under different time periods and span-to-depth ratios
时期 不同跨高比（L/H）时的计算值与参考值之比/% 10 7 6 5 4 3 瞬时 3.3 7.0 9.2 12.7 18.4 28.6 500 d 2.6 6.9 8.6 11.2 15.3 23.1 25 550 d 2.5 6.8 8.5 10.9 14.8 22.0
下载: 导出CSV
-
[1] 李聪, 聂建国, 周心怡, 等. 钢-混凝土连续组合梁桥负弯矩区抗裂设计[J]. 建筑结构学报, 2022, 43(3): 172-178.LI Cong, NIE Jian-guo, ZHOU Xin-yi, et al. Anti-cracking design for hogging moment regions of steel-concrete continuous composite beam bridges[J]. Journal of Building Structures, 2022, 43 (3): 172-178. [2] 贺绍华, 杨刚, 房腾鹏, 等. 带开孔板连接件的HSS-UHPC组合梁抗弯性能[J]. 交通运输工程学报, 2022, 22(6): 143-157. doi: 10.19818/j.cnki.1671-1637.2022.06.009 HE Shao-hua, YANG Gang, FANG Teng-peng, et al. Flexural performance of HSS-UHPC composite beams with perfobond strip connectors[J]. Journal of Traffic and Transportation Engineering, 2022, 22(6): 143-157. doi: 10.19818/j.cnki.1671-1637.2022.06.009 [3] 黄育凡, 方远威, 吴庆雄, 等. 工字组合梁整体式桥台节点受力性能与刚度计算[J]. 交通运输工程学报, 2025, 25(2): 329-341. doi: 10.19818/j.cnki.1671-1637.2025.05.022HUANG Yu-fan, FANG Yuan-wei, WU Qing-xiong, et al. Mechanical performance and stiffness calculation of integral abutment joints in Ⅰ-shaped composite girders[J]. Journal of Traffic and Transportation Engineering, 2025, 25(2): 329-341. doi: 10.19818/j.cnki.1671-1637.2025.05.022 [4] RANZI G. Locking problems in the partial interaction analysis of multi-layered composite beams[J]. Engineering Structures, 2008, 30(10): 2900-2911. doi: 10.1016/j.engstruct.2008.04.006 [5] LEPOURRY-NICOLLET C, HENG P, SOMJA H, et al. Influence of partial shear connection on the behaviour of U-shaped steel-concrete beams with L-shaped shear connectors[J]. Engineering Structures, 2023, 278: 115360. doi: 10.1016/j.engstruct.2022.115360 [6] NGUYEN Q H, MARTINELLI E, HJIAJ M. Derivation of the exact stiffness matrix for a two-layer Timoshenko beam element with partial interaction[J]. Engineering Structures, 2011, 33(2): 298-307. doi: 10.1016/j.engstruct.2010.10.006 [7] SCHNABL S, SAJE M, TURK G, et al. Locking-free two-layer Timoshenko beam element with interlayer slip[J]. Finite Elements in Analysis and Design, 2007, 43(9): 705-714. doi: 10.1016/j.finel.2007.03.002 [8] AYOUB A A. A force-based model for composite steel-concrete beams with partial interaction[J]. Journal of Constructional Steel Research, 2005, 61(3): 387-414. doi: 10.1016/j.jcsr.2004.08.004 [9] AYOUB A A, FILIPPOU F C. Mixed formulation of nonlinear steel-concrete composite beam element[J]. Journal of Structural Engineering (ASCE), 2000, 126(3): 371-381. doi: 10.1061/(ASCE)0733-9445(2000)126:3(371) [10] REDDY J N. A simple higher-order theory for laminated composite plates[J]. Journal of Applied Mechanics, 1984, 51(4): 745-752. doi: 10.1115/1.3167719 [11] CHAKRABARTI A, SHEIKH A H, GRIFFITH M, et al. Analysis of composite beams with partial shear interactions using a higher-order beam theory[J]. Engineering Structures, 2012, 36: 283-291. doi: 10.1016/j.engstruct.2011.12.019 [12] RANZI G, BRADFORD M A, UY B. A direct stiffness analysis of a composite beam with partial interaction[J]. International Journal for Numerical Methods in Engineering, 2004, 61(5): 657-672. doi: 10.1002/nme.1091 [13] FAELLA C, MARTINELLI E, NIGRO E. Steel-concrete composite beams in partial interaction: Closed-form "exact" expression of the stiffness matrix and the vector of equivalent nodal forces[J]. Engineering Structures, 2010, 32(9): 2744-2754. doi: 10.1016/j.engstruct.2010.04.044 [14] MARTINELLI E, FAELLA C, DI PALMA G. Shear-flexible steel-concrete composite beams in partial interaction: Closed-form "exact" expression of the stiffness matrix[J]. Journal of Engineering Mechanics, 2012, 138(2): 151-163. doi: 10.1061/(ASCE)EM.1943-7889.0000320 [15] SOUSA J B M. Exact finite elements for multilayered composite beam-columns with partial interaction[J]. Computers & Structures, 2013, 123: 48-57. [16] KEO P, NGUYEN Q H, SOMJA H, et al. Derivation of the exact stiffness matrix of shear-deformable multi-layered beam element in partial interaction[J]. Finite Elements in Analysis and Design, 2016, 112: 40-49. doi: 10.1016/j.finel.2015.12.004 [17] SUN Q K, ZHANG N, LIU X. A numerically stable exact method for analysis of partial-interaction composite beams based on Timoshenko beam theory[J]. Engineering Structures, 2022, 273: 115049. doi: 10.1016/j.engstruct.2022.115049 [18] BATTINI J M, NGUYEN Q H, HJIAJ M. Non-linear finite element analysis of composite beams with interlayer slips[J]. Computers & Structures, 2009, 87(13/14): 904-912. [19] LE GROGNEC P L, NGUYEN Q H, HJIAJ M. Plastic bifurcation analysis of a two-layer shear-deformable beam-column with partial interaction[J]. International Journal of Non-Linear Mechanics, 2014, 67: 85-94. doi: 10.1016/j.ijnonlinmec.2014.08.010 [20] OENG T, KEO P, GUEZOULI S, et al. Large displacement analysis of two-layer beam-columns taking into account slip and uplift[J]. Engineering Computations, 2023, 40(1): 265-295. [21] 樊健生, 聂建国, 王浩. 考虑收缩, 徐变及开裂影响的组合梁长期受力性能研究(Ⅰ)——试验及计算[J]. 土木工程学报, 2009, 42(3): 8-15.FAN Jian-sheng, NIE Jian-guo, WANG Hao. Long-term behavior of composite beams with shrinkage, creep and cracking(Ⅰ)—experiment and calculation[J]. China Civil Engineering Journal, 2009, 42(3): 8-15. [22] 樊健生, 聂鑫, 李全旺. 考虑收缩, 徐变及开裂影响的组合梁长期受力性能研究(Ⅱ)——理论分析[J]. 土木工程学报, 2009, 42(3): 16-22.FAN Jian-sheng, NIE Xin, LI Quan-wang. Long-term behavior of composite beams with shrinkage, creep and cracking(Ⅱ)—theoretical analysis[J]. China Civil Engineering Journal, 2009, 42(3): 16-22. [23] MARCELLO TARANTINO A, DEZI L. Creep effects in composite beams with flexible shear connectors[J]. Journal of Structural Engineering (ASCE), 1992, 118(8): 2063-2080. doi: 10.1061/(ASCE)0733-9445(1992)118:8(2063) [24] HE G H, LI X K. Weak-form quadrature element method for creep and shrinkage analysis of steel-concrete composite beams[J]. Journal of Engineering Mechanics, 2020, 146(4): 04020015. doi: 10.1061/(ASCE)EM.1943-7889.0001744 [25] ZHU L, SU R K L, HUO J X, et al. Test of the long-term behavior of curved steel-concrete composite box beams: Case study[J]. Journal of Bridge Engineering, 2021, 26(9): 05021009. doi: 10.1061/(ASCE)BE.1943-5592.0001762 [26] ERKMEN R E, BRADFORD M A. Time-dependent creep and shrinkage analysis of composite beams curved in-plan[J]. Computers & Structures, 2011, 89(1/2): 67-77. [27] MARTINELLI E. A general numerical model for simulating the long-term response of two-layer composite systems in partial interaction[J]. Composite Structures, 2021, 257: 112929. doi: 10.1016/j.compstruct.2020.112929 [28] MURAKAMI H. A laminated beam theory with interlayer slip[J]. Journal of Applied Mechanics, 1984, 51(3): 551-559. doi: 10.1115/1.3167673 [29] RANZI G, ZONA A. A steel-concrete composite beam model with partial interaction including the shear deformability of the steel component[J]. Engineering Structures, 2007, 29(11): 3026-3041. doi: 10.1016/j.engstruct.2007.02.007 [30] ZONA A, RANZI G. Finite element models for nonlinear analysis of steel-concrete composite beams with partial interaction in combined bending and shear[J], Finite Elements in Analysis and Design, 2011, 47(2): 98-118. doi: 10.1016/j.finel.2010.09.006 [31] AREIZA-HURTADO M, VEGA-POSADA C A, ARISTIZABAL-OCHOA J D. Stiffness matrix and loading vector of a two-layer Timoshenko composite beam[J]. Structures, 2019, 20: 20-32. doi: 10.1016/j.istruc.2019.02.014 [32] HJIAJ M, BATTINI J M, NGUYEN Q H. Large displacement analysis of shear deformable composite beams with interlayer slips[J]. International Journal of Non-Linear Mechanics, 2012, 47(8): 895-904. [33] NGUYEN Q H, HJIAJ M, LE GROGNEC P. Analytical approach for free vibration analysis of two-layer Timoshenko beams with interlayer slip[J]. Journal of Sound and Vibration, 2012, 331(12): 2949-2961. doi: 10.1016/j.jsv.2012.01.034 [34] 李夏元, 王磊, 陈建兵, 等. 考虑腹板等效剪切变形影响的单箱多室薄壁箱梁单元[J]. 长安大学学报(自然科学版), 2026, 46(1): 118-128.LI Xia-yuan, WANG Lei, CHEN Jian-bing, et al. Single-box multi-cell thin-walled box girder element considering equivalent shear deformation effect of webs[J]. Journal of Chang'an University (Natural Science Edition), 2026, 46(1): 118-128. [35] LE GROGNEC P, NGUYEN Q H, HJIAJ M. Exact buckling solution for two-layer Timoshenko beams with interlayer slip[J]. International Journal of Solids and Structures, 2012, 49(1): 143-150. doi: 10.1016/j.ijsolstr.2011.09.020 [36] NGUYEN Q H, HJIAJ M, UY B. Time-dependent analysis of composite beams with continuous shear connection based on a space-exact stiffness matrix[J]. Engineering Structures, 2010, 32(9): 2902-2911. doi: 10.1016/j.engstruct.2010.05.009 [37] 吕朝锋, 杨庆卫, 陈伟球. 收缩与徐变对钢-混凝土组合梁弯曲变形的影响分析[J]. 建筑结构学报, 2010, 31(7): 32-39.LV Chao-feng, YANG Qing-wei, CHEN Wei-qiu. Effects of shrinkage and creep strains on bending behavior of steel-concrete composite beams[J]. Journal of Building Structures, 2010, 31(7): 32-39. [38] GILBERT R I, BRADFORD M A. Time-dependent behavior of continuous composite beams[R]. Sydney: University of New South Wales, 1992. -
