Optimization model of medical UAV transportation network for biological sample leakage risk
Article Text (Baidu Translation)
-
摘要: 为保障生物样本低空运输的安全性，提出了医用无人机运输系统的多目标优化模型与求解方法；考虑无人机运输事故的随机性和生物样本的危险性，建立了医用无人机运输生物样本的风险度量模型；以总风险最小化和总成本最小化为目标，构建了医用无人机运输网络优化模型，根据模型的计算复杂度，通过改进NSGA-Ⅱ算法思路，设计了求解步骤；通过深圳市实例和多个测试算例验证了模型和算法的有效性。研究结果表明：新模型在3 023.51 s内为深圳市生物样本运输提供165个有效的运输网络优化方案；新建的风险度量模型可定量评估载货医用无人机的运输风险，相比于几类常见的风险度量模型，新模型求得的方案平均减少约18.32%的总成本，平均提升约1.3倍风险均摊度；针对不同规模的优化问题，改进算法能够在有限的求解时间内提供多个有效的非支配解，并保有一定的计算稳定性。建立的模型和求解算法可为生物样本低空运输与应急安全管理提供医用无人机运输网络规划方案和风险控制方法。Abstract: To ensure the safety of low-altitude transportation of biological samples, a multi-objective optimization model and a solution procedure are developed for the medical UAV transportation system. Considering the randomness of UAV transportation accidents, as well as the risk of biological sample leakage, a risk measurement model for medical UAV transportation is established. A medical UAV transportation network optimization model is built with the objectives of minimizing total cost and total risk. Considering the computational complexity of the proposed model, a modified NSGA-Ⅱ algorithm is adopted to design the solution procedure. Finally, a real-life case in Shenzhen, China, and several test cases are used to demonstrate the effectiveness of the proposed model and algorithm. The results show that the proposed model provides 165 effective transportation network optimization schemes for biological sample transportation in Shenzhen within 3 023.51 s. Compared with traditional risk models, the proposed risk measurement model quantitatively evaluates the transportation risk of cargo-carrying medical UAVs, and the obtained solutions reduce the total cost by an average of 18.32% and increase the degree of risk sharing by an average of 1.3 times. When solving optimization problems of different scales, the improved algorithm provides multiple non-dominated solutions within limited solution time and maintains a certain level of computational stability. The proposed model and solution algorithm provide medical UAV transportation network planning schemes and risk control methods for low-altitude transportation and emergency safety management of biological samples.
-
表 1 检测中心建设候选点信息
Table 1. Information on candidate locations for inspection centers
节点编号 固定建设成本/106元 最小检测量/(kg·d-1) 最大检测能力/(kg·d-1) 技术1 技术2 技术3 技术1 技术2 技术3 技术1 技术2 技术3 16 6.00 4.50 3.00 10.00 9.00 8.00 100.00 90.00 80.00 17 6.00 4.50 3.00 10.00 9.00 8.00 100.00 90.00 80.00 18 6.00 4.50 3.00 10.00 9.00 8.00 100.00 90.00 80.00
下载: 导出CSV
表 2 检测技术信息
Table 2. Information on inspection technologies
技术类型 病毒样本 血液样本 细胞样本 技术1 相容 相容 技术2 相容 相容 技术3 相容 相容
下载: 导出CSV
表 3 试验中心和处置中心建设候选点信息
Table 3. Information on candidate locations for testing centers and response centers
节点编号 固定成本/106元 最大能力/(kg·d-1) 节点编号 固定成本/106元 最大能力/(kg·d-1) 19 2.00 100.00 22 2.20 90.00 20 1.80 85.00 23 2.80 80.00 21 3.00 90.00 24 2.80 85.00
下载: 导出CSV
表 4 各类优化方案的计算结果
Table 4. Computational results of different optimization schemes
优化方案 检测中心(检测技术) 试验中心 处置中心 总成本/ 107元 总风险/ m3 收集路线(生物样本) 总成本最小 16(2), 18(3) 20 22 1.15 128.22 16-7-3-8-6-10-9-11-14-15-2-4-12-5-1-16(病毒样本)；
16-13-16(病毒样本)；18-1-2-4-9-11-5-12-18(血液样本)；
18-10-7-14-3-8-6-15-13-18(血液样本);
16-7-3-8-11-9-15-16(细胞样本)；
18-10-6-12-4-2-1-5-14-13-18(细胞样本)总风险最小 16(1), 16(2) 19, 20, 21 22, 23, 24 2.51 36.24 16-3-8-11-13-14-16(病毒样本)；
16-5-10-2-15-4-7-6-12-1-9-16(病毒样本)；
16-8-5-12-3-2-16(血液样本)；
16-11-4-13-9-10-14-15-7-1-6-16(血液样本)；
16-8-3-15-9-5-12-4-16(细胞样本)；
16-10-2-7-6-1-11-14-13-16(细胞样本)推荐方案 16(2), 16(3) 19, 20, 21 22, 23, 24 2.22 77.69 16-3-5-8-6-4-15-16(病毒样本)；
16-13-9-7-1-10-14-12-2-11-16(病毒样本)；
16-11-3-5-4-15-16(血液样本)；
16-13-9-7-1-10-14-2-12-8-6-16(血液样本)；
16-14-12-3-15-4-11-5-16(细胞样本)；
16-6-8-10-9-7-1-2-13-16(细胞样本)
下载: 导出CSV
表 5 风险度量模型的对比结果
Table 5. Comparativeresults of risk measurement models
风险度量模型 总成本/107元 均摊运输风险 传统风险度量模型 3.09 0.67 箱式模型 2.51 0.81 高斯烟羽模型 2.28 0.39 本文模型 2.51 0.27
下载: 导出CSV
表 6 改进算法与常规多目标求解方法的对比结果
Table 6. Comparative results of the proposed algorithm and conventional multi-objective solution methods
求解方法 求解时间/s Pareto解数量 线性加权 19 269.51 11 增广域约束 12 981.02 10 遗传算法 8 741.93 48 本文改进算法 3 023.51 165
下载: 导出CSV
表 7 改进NSGA-Ⅱ算法与常规NSGA-Ⅱ算法测试对比结果
Table 7. Comparative results of the improved NSGA-Ⅱ algorithm and the conventional NSGA-Ⅱ algorithm
算法 推荐方案的总成本/107元 推荐方案的总风险范围/m3 Pareto解的数量 求解时间/s 常规NSGA-Ⅱ 2.29 93.10 144 2 821.48 改进NSGA-Ⅱ 2.22 77.69 165 3 023.51 变化率/% -3.06 -16.55 14.58 7.16
下载: 导出CSV
表 8 NSGA-Ⅱ算法改进前后对比
Table 8. Comparison of NSGA-Ⅱ before and after improvement
迭代测试组 迭代次数 求解方法 推荐方案的平均成本/107元 推荐方案的平均风险范围/m3 平均求解时间/s Pareto解的平均数量 1 1 000 常规NSGA-Ⅱ算法 2.13 90.67 2 761.53 141 改进NSGA-Ⅱ算法 2.01 76.93 2 973.92 162 变化率/% -5.63 -15.15 7.69 14.89 2 3 000 常规NSGA-Ⅱ算法 1.98 89.35 5 310.29 150 改进NSGA-Ⅱ算法 1.86 75.06 5 847.23 167 变化率/% -6.06 -15.99 10.11 11.33 3 5 000 常规NSGA-Ⅱ算法 1.93 86.42 11 285.22 149 改进NSGA-Ⅱ算法 1.84 74.95 11 863.72 164 变化率/% -4.66 -13.27 5.13 10.07
下载: 导出CSV
表 9 事故概率的敏感性测试
Table 9. Sensitivity analysis for incident probability
测试组 平均总成本/ 107元 平均总风险范围/ m3 Pareto解的平均数量 测试组1 2.20 835.09 117 测试组2 2.25 5.73 131 推荐方案 2.22 77.69 165
下载: 导出CSV
-
[1] 刘长石, 吴张, 周愉峰, 等. 疫区应急物资供应的卡车-无人机动态协同配送路径优化[J]. 系统科学与数学, 2022, 42(11): 3027-3043.LIU Chang-shi, WU Zhang, ZHOU Yu-feng, et al. The optimization of dynamic and cooperative truck-drone distribution routes for emergency supplies delivery in pandemic areas[J]. Journal of Systems Science and Mathematical Sciences, 2022, 42(11): 3027-3043. [2] 刘子豪, 赵佳虹. 鲁棒感知风险下医疗废物回收系统优化研究[J]. 中国安全科学学报, 2022, 32(12): 188-194.LIU Zi-hao, ZHAO Jia-hong. Research on optimization of medical waste recycling system under robust perceived risk[J]. China Safety Science Journal, 2022, 32(12): 188-194. [3] 王文涛, 甘旭升, 吴亚荣, 等. 考虑不确定性的低空无人机运行风险评估方法[J]. 现代防御技术, 2022, 50(5): 14-21.WANG Wen-tao, GAN Xu-sheng, WU Ya-rong, et al. Low-altitude UAV operation risk assessment method considering the uncertainty[J]. Modern Defence Technology, 2022, 50(5): 14-21. [4] LI Q Y, WU Q G, TU H Y, et al. Ground risk assessment for unmanned aircraft focusing on multiple risk sources in urban environments[J]. Processes, 2023, 11(2): 542. doi: 10.3390/pr11020542 [5] 马涛, 吴俊, 唐樊龙, 等. 基于多源数据与大模型的无人机巡航风险识别技术[J]. 交通运输工程学报, 2026, 26(3): 75-88. doi: 10.19818/j.cnki.1671-1637.2026.036MA Tao, WU Jun, TANG Fan-long, et al. Unmanned aerial vehicle cruise risk identification technology based on multi-source data and large models[J]. Journal of Traffic and Transportation Engineering, 2026, 26(3): 75-88. doi: 10.19818/j.cnki.1671-1637.2026.036 [6] PRIMATESTA S, RIZZO A, LA COUR-HARBO A. Ground risk map for unmanned aircraft in urban environments[J]. Journal of Intelligent and Robotic Systems, 2020, 97(3): 489-509. [7] ZHANG G Y, ZHANG J P, HE B S, et al. An optimisation model of hierarchical facility location problem for urban last-mile delivery with drones[J]. Transportmetrica A: Transport Science, 2024: 1-29. [8] 张宏宏, 甘旭升, 孙静娟, 等. 基于STPA-TOPAZ的低空无人机冲突解脱安全性分析[J]. 航空学报, 2022, 43(7): 255-267.ZHANG Hong-hong, GAN Xu-sheng, SUN Jing-juan, et al. Analysis of low altitude UAV conflict resolution safety based on STPA-TOPAZ[J]. Acta Aeronautica et Astronautica Sinica, 2022, 43(7): 255-267. [9] 胡莘婷, 吴宇. 面向城市飞行安全的无人机离散型多路径规划方法[J]. 航空学报, 2021, 42(6): 452-463.HU Xin-ting, WU Yu. Risk-based discrete multi-path planning method for UAVs in urban environments[J]. Acta Aeronautica et Astronautica Sinica, 2021, 42(6): 452-463. [10] 张薇, 何若俊. 面向物联网数据收集的无人机自主路径规划[J]. 航空学报, 2024, 45(8): 229-243.ZHANG Wei, HE Ruo-jun. Autonomous trajectory design for IoT data collection by UAV[J]. Acta Aeronautica et Astronautica Sinica, 2024, 45(8): 229-243. [11] PANG B Z, HU X T, DAI W, et al. UAV path optimization with an integrated cost assessment model considering third-party risks in metropolitan environments[J]. Reliability Engineering and System Safety, 2022, 222: 108399. doi: 10.1016/j.ress.2022.108399 [12] 王祝, 张梦通, 张振鹏, 等. 基于多指标动态优先级的无人机协同路径规划[J]. 航空学报, 2024, 45(4): 256-269.WANG Zhu, ZHANG Meng-tong, ZHANG Zhen-peng, et al. Multi-UAV cooperative path planning based on multi-index dynamic priority[J]. Acta Aeronautica et Astronautica Sinica, 2024, 45(4): 256-269. [13] 赵江, 张璇, 池沛, 等. 空地无人集群自调节控制与动态路径规划方法[J]. 航空学报, 2024, 45(16): 207-226.ZHAO Jiang, ZHANG Xuan, CHI Pei, et al. Self-adaptive formation control and dynamic path planning for air-ground heterogeneous swarm[J]. Acta Aeronautica et Astronautica Sinica, 2024, 45(16): 207-226. [14] SALAMA M R, SRINIVAS S. Collaborative truck multi- drone routing and scheduling problem: Package delivery with flexible launch and recovery sites[J]. Transportation Research Part E: Logistics and Transportation Review, 2022, 164: 102788. doi: 10.1016/j.tre.2022.102788 [15] MENG S S, GUO X P, LI D, et al. The multi-visit drone routing problem for pickup and delivery services[J]. Transportation Research Part E: Logistics and Transportation Review, 2023, 169: 102990. doi: 10.1016/j.tre.2022.102990 [16] ZHOU H, QIN H, CHENG C, et al. An exact algorithm for the two-echelon vehicle routing problem with drones[J]. Transportation Research Part B: Methodological, 2023, 168: 124-150. doi: 10.1016/j.trb.2023.01.002 [17] TINIÇ G O, KARASAN O E, KARA B Y, et al. Exact solution approaches for the minimum total cost traveling salesman problem with multiple drones[J]. Transportation Research Part B: Methodological, 2023, 168: 81-123. doi: 10.1016/j.trb.2022.12.007 [18] 羊钊, 齐洪彪, 于阳阳, 等. 风险规避与组合策略融合的多无人机协同路径规划方法[J]. 交通运输工程学报, 2026, 26(3): 140-158. doi: 10.19818/j.cnki.1671-1637.2026.089YANG Zhao, QI Hong-biao, YU Yang-yang, et al. Integrated risk avoidance and hybrid strategy for multi-UAV cooperative path planning[J]. Journal of Traffic and Transportation Engineering, 2026, 26(3): 140-158. doi: 10.19818/j.cnki.1671-1637.2026.089 [19] 赵佳虹, 柯紫琪, 吴文俊, 等. 考虑辐射风险的核污染废物回收系统优化[J]. 安全与环境学报, 2024, 24(10): 4014-4021.ZHAO Jia-hong, KE Zi-qi, WU Wen-jun, et al. Optimization of a nuclear contaminated waste recycling system considering radiation risks[J]. Journal of Safety and Environment, 2024, 24(10): 4014-4021. [20] VERMA M, VERTER V. Railroad transportation of dangerous goods: Population exposure to airborne toxins[J]. Computers and Operations Research, 2007, 34(5): 1287-1303. doi: 10.1016/j.cor.2005.06.013 [21] WANG Z Y, RANGAIAH G P. Application and analysis of methods for selecting an optimal solution from the Pareto-optimal front obtained by multi-objective optimization[J]. Industrial & Engineering Chemistry Research, 2017, 56(2): 560-574. [22] ZHAO J H, VERTER V. A bi-objective model for the used oil location-routing problem[J]. Computers & Operations Research, 2015, 62: 157-168. [23] ZHAO J H, CHEN J F, KE G Y, et al. A bi-objective data-driven chance-constrained optimization for sustainable urban medical waste management[J]. Expert Systems with Applications, 2025, 267: 126213. doi: 10.1016/j.eswa.2024.126213 [24] ZHAO J H, WU B H, KE G Y. A bi-objective robust optimization approach for the management of infectious wastes with demand uncertainty during a pandemic[J]. Journal of Cleaner Production, 2021, 314: 127922. doi: 10.1016/j.jclepro.2021.127922 -
