MPC-based control strategy for conflict resolution between vehicles and aircraft on airport
Article Text (Baidu Translation)
-
摘要: 为解决机场场面服务车辆与航空器在滑行道与行车道交叉点频繁发生冲突的问题，提出了一种基于模型预测控制（MPC）的机场自动驾驶车辆与航空器交叉冲突消解方法。分析了机场场面车-机交汇的典型运行场景，明确了车辆在与航空器交叉冲突中需要满足的纵向动力学约束和航空器安全边界要求；在此基础上，提出将航空器及其安全边距经过冲突区域的时段定义为动态红灯时间窗约束，并以车辆能耗最小化和通行效率最大化为优化目标，建立了车辆MPC模型；采用序列二次规划方法对非线性约束优化问题进行滚动求解，实时生成了车辆的最优速度与加速度控制序列；结合天津滨海国际机场的真实场景数据开展仿真试验，并设置了多组随机工况进行对比分析。研究结果表明：在所提出的MPC策略下，车辆能够避免与航空器发生潜在冲突，与常态人工驾驶和理想人工驾驶相比，平均能耗降低14.81%和14.27%，平均通行时间缩短6.48%和5.70%，轨迹平稳性和控制效果均表现出明显优势。研究结果表明，提出的冲突消解控制策略不仅能够提高机场场面车辆运行的安全性与经济性，还为未来机场自动驾驶车辆的应用与推广提供了有效的理论支撑和技术参考。Abstract: To address the frequent conflicts between airport ground service vehicles and aircraft at intersections of taxiways and roadways, a model predictive control (MPC)-based conflict resolution method was proposed for airport autonomous vehicles and aircraft. The typical operation scenarios of ground vehicle-aircraft intersections on the airport were analyzed. The longitudinal dynamic constraints of vehicles and the safety boundary requirements of aircraft in conflict situations were clarified. On this basis, the period when the aircraft and its safety clearance passed through the conflict area was defined as a dynamic red light time window constraint. With the objectives of minimizing vehicle energy consumption and maximizing traffic efficiency, an MPC model for vehicle was established. A sequential quadratic programming method was employed to solve the nonlinear constrained optimization problem in a rolling manner, thereby generating optimal speed and acceleration control sequences for vehicles in real time. Simulation experiments were conducted using real-world scenario data from Tianjin Binhai International Airport. Multiple sets of random operating conditions were also designed for comparative analysis. Research results show that, with the proposed MPC strategy, the vehicle can avoid potential conflicts with aircraft. Compared with conventional human driving and idealized human driving, the average energy consumption is reduced by 14.81% and 14.27%, respectively, and the average travel time is shortened by 6.48% and 5.70%. The trajectory smoothness and control performance are both significantly superior. These findings indicate that the proposed conflict resolution control strategy not only enhances the safety and efficiency of airport ground vehicle operations but also provides practical theoretical support and technical reference for the future application and popularization of autonomous vehicles on airports.
-
图 9 有无MPC的平均能耗和驾驶时长对比
Figure 9. Comparison of average energy consumption and travel time with and without MPC
图 10 有无MPC的车辆及航空器时空轨迹
Figure 10. Spatiotemporal trajectories of vehicles and aircraft with and without MPC
表 1 仿真参数
Table 1. Simulation parameters
含义 数值 车辆长度/m 7.45 车辆质量/kg 7 650 车辆最大加速度/（m∙s-2） 3 车辆最小加速度/（m∙s-2） -3 车辆最大速度/（m∙s-1） 8.3 航空器翼展/m 34.09 航空器机长/m 37.57 航空器滑行最大加速度/（m∙s-2） 5 航空器滑行最小加速度/（m∙s-2） -0.98 航空器最大滑行速度/（m∙s-1） 13 航空器侧向净空距离/m 7.5 航空器前向净空距离/m 50 航空器尾流距离/m 30 车辆迎风面积/m2 9 空气阻力系数 0.32 空气密度/（kg∙m-3） 1.23 重力加速度/（m∙s-2） 9.81 滚动阻力系数 0.018 通行效率项权重系数 30 预测步长 100 执行步长 1 时间间隔/s 0.5 驾驶员驾驶风格系数 U（0.9，1.1） 车辆自由行驶时加速度/（m∙s-2） 2 车辆自由行驶时减速度/（m∙s-2） -1 驾驶员观察距离/m 25.45 驾驶员估计航空器远离距离/m 425.57 驾驶员估计航空器接近距离/m 200 驾驶员随机减速概率 0.2
下载: 导出CSV
-
[1] 新华社. 2024年我国民用机场两大运输生产指标均创历史新高[EB/OL]. 中国政府网, (2025-04-22). https://www.gov.cn/yaowen/liebiao/202504/content_7020309.htm .Xinhua News Agency. 2024: Two major transport production indicators of China's civil airports reached record highs [EB/OL]. The State Council of the People's Republic of China, (2025-04-22).https://www.gov.cn/yaowen/liebiao/202504/content_7020309.htm .[2] 易奎, 张雨乐, 庄夏, 等. 民航车辆调度现状分析及发展趋势综述[J]. 科学技术与工程, 2024, 24(36): 15321-15333.YI Kui, ZHANG Yu-le, ZHUANG Xia, et al. Review of the analysis of current situation and research on development trends of civil aviation vehicle dispatch[J]. Science Technology and Engineering, 2024, 24(36): 15321-15333. [3] 安鑫, 刘一. 车路协同自动驾驶技术在民航机场的应用前景展望[J]. 交通工程, 2020, 20(4): 57-61, 67.AN Xin, LIU Yi. The application prospect of vehicle-road collaborative autonomous driving technology in civil aviation airport[J]. Journal of Transportation Engineering, 2020, 20(4): 57-61, 67. [4] SHVETSOV A V. Analysis of accidents resulting from the interaction of air and ground vehicles at airports[J]. Transportation Research Procedia, 2021, 59: 21-28. doi: 10.1016/j.trpro.2021.11.093 [5] GUO R J, WU J W, JI F, et al. Analysis of traffic safety in airport aircraft activity areas based on Bayesian networks and fault trees[J]. Digital Transportation and Safety, 2024, 3(1): 8-18. doi: 10.48130/dts-0024-0002 [6] 姬雨初, 闫宗吉. 机坪行车道交叉口特种车辆运行控制策略[J]. 电子测量与仪器学报, 2025, 39(3): 226-234.JI Yu-chu, YAN Zong-ji. Operation control strategy of specialized vehicles at apron lane intersection[J]. Journal of Electronic Measurement and Instrumentation, 2025, 39(3): 226-234. [7] DENG W, ZHANG L R, ZHOU X B, et al. Multi-strategy particle swarm and ant colony hybrid optimization for airport taxiway planning problem[J]. Information Sciences, 2022, 612: 576-593. doi: 10.1016/j.ins.2022.08.115 [8] LIANG M, DELAHAYE D, MARECHAL P. Conflict-free arrival and departure trajectory planning for parallel runway with advanced point-merge system[J]. Transportation Research Part C: Emerging Technologies, 2018, 95: 207-227. doi: 10.1016/j.trc.2018.07.006 [9] 李慧盈, 张明, 刘思涵, 等. 基于冲突类型差异的航空器场面滑行路径规划[J]. 武汉理工大学学报(交通科学与工程版), 2022, 46(3): 400-405.LI Hui-ying, ZHANG Ming, LIU Si-han, et al. Aircraft taxiing path planning based on differences in conflict types[J]. Journal of Wuhan University of Technology (Transportation Science & Engineering), 2022, 46 (3): 400-405. [10] 许敖洋, 赵浩然, 马雪, 等. 基于最少油耗的航空器冲突解脱方法研究[J]. 科技创新与应用, 2023, 13(10): 17-20.XU Ao-yang, ZHAO Hao-ran, MA Xue, et al. Research on aircraft conflict resolution methods based on minimum fuel consumption[J]. Technology Innovation and Application, 2023, 13(10): 17-20. [11] 包丹文, 姚馨宇, 刘建荣, 等. 基于动态优先级的机坪车辆避冲突运行规划方法[J]. 华东交通大学学报, 2024, 41(4): 99-107.BAO Dan-wen, YAO Xin-yu, LIU Jian-rong, et al. Operation planning method for airport support vehicle collision avoidance based on dynamic priority[J]. Journal of East China Jiaotong University, 2024, 41(4): 99-107. [12] ZHAO N N, LI N, SUN Y, et al. Research on aircraft surface taxi path planning and conflict detection and resolution[J]. Journal of Advanced Transportation, 2021, 2021: 9951206. [13] 唐铁桥, 曹峰, 王芃, 等. 飞机可持续滑行技术理论进展与应用挑战[J]. 交通运输工程学报, 2026, 26(1): 8-30.TANG Tie-qiao, CAO Feng, WANG Peng, et al. Theoretical advances and application challenges of sustainable aircraft taxiing technology[J]. Journal of Traffic and Transportation Engineering, 2026, 26(1): 8-30. [14] 何庶, 卢朝阳, 王颜颜, 等. 侧向跑道机场滑行路径优化[J]. 科学技术与工程, 2021, 21(20): 8695-8701.HE Shu, LU Chao-yang, WANG Yan-yan, et al. Lateral runway airport based on improved genetic algorithm glide path optimization[J]. Science Technology and Engineering, 2021, 21 (20): 8695-8701. [15] 康瑞, 杨凯. 考虑驾驶方式的车辆与航空器交叉冲突评估[J]. 中国安全生产科学技术, 2023, 19(2): 218-223.KANG Rui, YANG Kai. Assessment on cross conflict of vehicle and aircraft considering driving modes[J]. Journal of Safety Science and Technology, 2023, 19(2): 218-223. [16] 常鑫, 马光辉, 高建树, 等. 考虑碰撞概率的机场场面交叉口冲突预警方法[J]. 科学技术与工程, 2025, 25(11): 4776-4785.CHANG Xin, MA Guang-hui, GAO Jian-shu, et al. Collision warning method for unmanned aerial vehicles in airports based on collision probability[J]. Science Technology and Engineering, 2025, 25(11): 4776-4785. [17] LUO Q, LIU H M, LIU C, et al. Multi-strategy cooperative scheduling for airport specialized vehicles based on digital twins[J]. Scientific Reports, 2024, 14(1): 15533. doi: 10.1038/s41598-024-66350-0 [18] LIU Y H, WU J J, TANG J, et al. Scheduling optimisation of multi-type special vehicles in an airport[J]. Transportmetrica B: Transport Dynamics, 2022, 10(1): 954-970. doi: 10.1080/21680566.2021.1983484 [19] ZHANG J C, CHONG X L, WEI Y Z, et al. Optimization of apron support vehicle operation scheduling based on multi-layer coding genetic algorithm[J]. Applied Sciences, 2022, 12(10): 5279. doi: 10.3390/app12105279 [20] BAO D W, ZHOU J Y, ZHANG Z Q, et al. Mixed fleet scheduling method for airport ground service vehicles under the trend of electrification[J]. Journal of Air Transport Management, 2023, 108: 102379. doi: 10.1016/j.jairtraman.2023.102379 [21] FU W G, LI J W, LIAO Z, et al. A bi-objective optimization approach for scheduling electric ground-handling vehicles in an airport[J]. Complex & Intelligent Systems, 2025, 11(4): 209. [22] ZHOU J N, WU Y X, CAO Z G, et al. Learning large neighborhood search for vehicle routing in airport ground handling[J]. IEEE Transactions on Knowledge and Data Engineering, 2023, 35(9): 9769-9782. doi: 10.1109/TKDE.2023.3249799 [23] 张凤, 汤晓鹏, 刘兵飞. 机场飞行区无人驾驶清水车优化调度方法[J]. 交通信息与安全, 2022, 40(2): 82-90.ZHANG Feng, TANG Xiao-peng, LIU Bing-fei. An optimization method for scheduling autonomous potable water service vehicles at airfields[J]. Journal of Transport Information and Safety, 2022, 40(2): 82-90. [24] 邢志伟, 李斯, 罗谦. 机场道面除冰雪车辆队形控制模型[J]. 交通运输工程学报, 2019, 19(4): 182-190. doi: 10.19818/j.cnki.1671-1637.2019.04.017 XING Zhi-wei, LI Si, LUO Qian. Formation control model of airport pavement deicing vehicles[J]. Journal of Traffic and Transportation Engineering, 2019, 19(4): 182-190. doi: 10.19818/j.cnki.1671-1637.2019.04.017 [25] HULT R, ZANON M, GROS S, et al. Optimal coordination of automated vehicles at intersections: Theory and experiments[J]. IEEE Transactions on Control Systems Technology, 2019, 27(6): 2510-2525. doi: 10.1109/TCST.2018.2871397 [26] SOMAN S, ZANON M, BEMPORAD A. Learning-based stochastic model predictive control for autonomous driving at uncontrolled intersections[J]. IEEE Transactions on Intelligent Transportation Systems, 2025, 26(2): 1538-1546. doi: 10.1109/TITS.2024.3510041 [27] BAUTISTA-MONTESANO R, GALLUZZI R, RUAN K R, et al. Autonomous navigation at unsignalized intersections: a coupled reinforcement learning and model predictive control approach[J]. Transportation Research Part C: Emerging Technologies, 2022, 139: 103662. doi: 10.1016/j.trc.2022.103662 [28] 许曼晨, 于镝, 赵理, 等. 基于MAPPO的无信号灯交叉口自动驾驶决策[J]. 吉林大学学报(信息科学版), 2024, 42(5): 790-798.XU Man-chen, YU Di, ZHAO Li, et al. Autonomous driving decision-making at signal-free intersections based on MAPPO[J]. Journal of Jilin University (Information Science Edition), 2024, 42(5): 790-798. [29] LIBERATI F, DONSANTE M, TORTORELLI A. Single intersection MPC traffic signal control in presence of automated vehicles[J]. IEEE Transactions on Control Systems Technology, 2025, 33(4): 1432-1446. doi: 10.1109/TCST.2024.3449188 [30] 李兵兵, 庄伟超, 刘昊吉, 等. 基于自学习型MPC的网联电动汽车生态驾驶控制策略研究[J]. 机械工程学报, 2024, 60(10): 453-462.LI Bing-bing, ZHUANG Wei-chao, LIU Hao-ji, et al. Research on eco-driving control strategy of connected electric vehicle based on learning-MPC[J]. Journal of Mechanical Engineering, 2024, 60(10): 453-462. [31] 赵树恩, 冷姚, 邵毅明. 车辆多目标自适应巡航显式模型预测控制[J]. 交通运输工程学报, 2020, 20(3): 206-216. doi: 10.19818/j.cnki.1671-1637.2020.03.019 ZHAO Shu-en, LENG Yao, SHAO Yi-ming. Explicit model predictive control of multi-objective adaptive cruise of vehicle[J]. Journal of Traffic and Transportation Engineering, 2020, 20(3): 206-216. doi: 10.19818/j.cnki.1671-1637.2020.03.019 [32] 包丹文, 陈卓, 姚馨宇, 等. 基于混合策略的机坪车辆主动式实时调度方法[J]. 交通运输工程学报, 2024, 24(3): 251-265. doi: 10.19818/j.cnki.1671-1637.2024.03.018 BAO Dan-wen, CHEN Zhuo, YAO Xin-yu, et al. Pro-active real-time scheduling approach of apron vehicles based on mixed strategy[J]. Journal of Traffic and Transportation Engineering, 2024, 24(3): 251-265. doi: 10.19818/j.cnki.1671-1637.2024.03.018 [33] 毕军, 回晶, 成沛璇, 等. 机坪货运保障人员配置计划优化方法[J]. 交通运输工程学报, 2025, 25(4): 254-266. doi: 10.19818/j.cnki.1671-1637.2025.04.018 BI Jun, HUI Jing, CHENG Pei-xuan, et al. Optimization method of personnel allocation plan for apron cargo support[J]. Journal of Traffic and Transportation Engineering, 2025, 25(4): 254-266. doi: 10.19818/j.cnki.1671-1637.2025.04.018 -
