不同内外部耦合激励对高铁齿轮箱箱体动态特性的影响

张建超; 张博文; 齐星科; 张永超

doi:10.19818/j.cnki.1671-1637.2025.03.017

不同内外部耦合激励对高铁齿轮箱箱体动态特性的影响

doi: 10.19818/j.cnki.1671-1637.2025.03.017

1.
石家庄铁道大学省部共建交通工程结构力学行为与系统安全国家重点实验室，河北石家庄 050043
2.
石家庄铁道大学机械工程学院，河北石家庄 050043

基金项目:

国家自然科学基金项目 11872256

详细信息

作者简介:
张建超(1977-)，男，河北唐山人，石家庄铁道大学教授，工学博士，从事机电系统故障诊断研究

中图分类号: U270.3
计量
- 文章访问数: 172
- HTML全文浏览量: 41
- PDF下载量: 18
- 被引次数: 0
出版历程
- 收稿日期: 2024-06-11
- 录用日期: 2025-04-30
- 修回日期: 2025-01-15
- 刊出日期: 2025-06-28

Influence of different internal and external coupling excitations on dynamic characteristics of high-speed railway gearbox housing

1.
State Key Laboratory of Mechanical behavior and System Safety of Traffic Engineering Structures, Shijiazhuang Tiedao University, Shijiazhuang 050043, Hebei, China
2.
School of Mechanical Engineering, Shijiazhuang Tiedao University, Shijiazhuang 050043, Hebei, China

Funds:

National Natural Science Foundation of China 11872256

More Information

Corresponding author: ZHANG Jian-chao (1977-), male, professor, PhD, zjc@stdu.edu.cn

Article Text (Baidu Translation)

摘要

摘要: 从概率统计和疲劳损伤角度，分别诠释了箱体振动加速度变化特点及动应力变化对箱体不同部位的影响；基于矢量控制理论和机车车辆多体动力学理论，建立了高速列车牵引电机控制模型和考虑柔性箱体的高速列车刚柔耦合模型，通过联合仿真方法搭建了高速列车机电耦合模型；基于核密度估计方法拟合出了箱体振动加速度的概率密度函数曲线；结合箱体材料疲劳试验计算了损伤参数。分析结果表明：箱体小轴承孔上方纵向、大轴承孔上方横向与垂向的加速度概率密度函数均存在由单主峰变为双主峰的过程，且概率密度图像逐渐变宽变矮，说明这3个方向的振动加速度受激励变化影响较大，此外概率密度函数图像出现双主峰时皆包含车轮多边形激励，说明该激励导致振动加速度信号在两侧分布较为密集；小轴承孔上方和油位观察孔处谐波转矩激励的疲劳损伤贡献较明显，使这两处损伤参数约增长0.05，之后随工况变化这两处损伤参数基本保持不变，大轴承孔上方轨道不平顺激励的疲劳损伤贡献最大，损伤参数由0.14增长至0.68，齿面观察孔处车轮多边形激励的疲劳损伤贡献相比其他激励要大，损伤参数由0.19增长至0.60，大轴承孔上方与齿面观察孔两处位置的损伤参数涨幅变化较为显著，因此，在检修时应重点关注。
- 高速列车 /
- 齿轮箱箱体 /
- 联合仿真 /
- 振动特性 /
- 核密度估计 /
- 疲劳损伤
Abstract: The changes in housing vibration acceleration and the influence on various parts of the housing from dynamic stress were interpreted from the perspectives of probability statistics and fatigue damage. Based on vector control theory and multibody dynamics theory for locomotives, a traction motor control model for high-speed train and a rigid-flexible coupling model of high-speed train with a flexible housing were established. The mechatronic coupling model of the high-speed train was constructed through joint simulation. The probability density function curve of housing vibration acceleration was fitted using kernel density estimation. Combined with fatigue testing of housing materials, the damage parameters were calculated. Analysis results show that the probability density functions of vibration acceleration above the small bearing hole in the longitudinal direction, and above the large bearing hole in the horizontal and vertical directions, all undergo a process of changing from a single peak to double peaks. The probability density graphs gradually widen and flatten, indicating that the vibration acceleration in these three directions is significantly affected by excitation changes. When the probability density function exhibits double peaks, they all include wheel polygonal excitation, suggesting that this excitation leads to a more concentrated distribution of vibration acceleration signals on both sides. The fatigue damage contribution from harmonic torque excitation above the small bearing hole and at the oil level observation hole is more prominent, with the damage parameters increasing by about 0.05 at these two locations. These damage parameters remain almost unchanged with the change in working conditions. The fatigue damage contribution from track irregularity excitation above the large bearing hole is the largest, with the damage parameters increasing from 0.14 to 0.68. The fatigue damage contribution from wheel polygonal excitation at the tooth surface observation hole is larger compared to other excitations, with the damage parameters increasing from 0.19 to 0.60. The change in damage parameters at the large bearing hole and the tooth surface observation hole is more significant, so special attention should be given to these areas during maintenance.
- high-speed train /
- gearbox housing /
- joint simulation /
- vibration characteristic /
- kernel density estimation /
- fatigue damage

HTML全文

图 1 高速列车动力学模型

Figure 1. High-speed train dynamics model

下载: 全尺寸图片幻灯片

图 2 测点振动加速度时域对比

Figure 2. Time-domain comparison of vibration accelerations at measuring points

下载: 全尺寸图片幻灯片

图 3 测点B垂向振动加速度频域

Figure 3. Vertical vibration acceleration frequency-domain of measuring point B

下载: 全尺寸图片幻灯片

图 4 牵引电机控制原理

Figure 4. Control principle of traction motor

下载: 全尺寸图片幻灯片

图 5 高速列车机电耦合模型原理

Figure 5. Principle of electromechanical coupling model for high-speed trains

下载: 全尺寸图片幻灯片

图 6 箱体测点位置

Figure 6. Location of housing measuring points

下载: 全尺寸图片幻灯片

图 7 齿轮接触特性分析

Figure 7. Analysis of gear contact characteristics

下载: 全尺寸图片幻灯片

图 8 测点A振动加速度时频分析

Figure 8. Time-frequency analysis of vibration acceleration at measuring point A

下载: 全尺寸图片幻灯片

图 9 理想转矩驱动下箱体不同部位动应力均方根

Figure 9. Root mean square values of dynamic stress in different parts of housing under ideal torque drive

下载: 全尺寸图片幻灯片

图 10 核密度估计结果与直方图对比

Figure 10. Comparison between kernel density estimation results and histograms

下载: 全尺寸图片幻灯片

图 11 箱体纵向加速度概率密度

Figure 11. Probability densities of longitudinal acceleration of housing

下载: 全尺寸图片幻灯片

图 12 箱体横向加速度概率密度

Figure 12. Probability densities of lateral acceleration of housing

下载: 全尺寸图片幻灯片

图 13 箱体垂向加速度概率密度

Figure 13. Probability densities of vertical acceleration of housing

下载: 全尺寸图片幻灯片

图 14 工况4下齿轮时变啮合刚度

Figure 14. Time-varying mesh stiffnesses of gears under working condition 4

下载: 全尺寸图片幻灯片

图 15 不同工况下的箱体动应力分布

Figure 15. Dynamic stress distributions of housing under different working conditions

下载: 全尺寸图片幻灯片

图 16 箱体不同部位损伤参数

Figure 16. Damage parameters of different parts of housing

下载: 全尺寸图片幻灯片

表 1 工况激励类型

Table 1. Incentive types for working conditions

工况	激励类型
1	理想转矩激励
2	谐波转矩激励
3	谐波转矩+轨道不平顺激励
4	谐波转矩+车轮多边形激励
5	谐波转矩+复合轮轨激励

下载: 导出CSV

表 2 各个工况下齿轮接触特性

Table 2. Gear contact characteristics under various working conditions

工况	圆周力均方根值/N	轴向力均方根值/N	径向力均方根值/N	传递误差峰峰值/um
1	12 029.30	3 921.74	4 723.70	6.01
2	12 039.00	3 952.15	4 754.41	13.39
4	12 060.80	3 962.02	4 761.15	17.64

下载: 导出CSV
