Autonomous avoidance decision-making and control method for eVTOL aircraft under non-cooperative differential games
-
摘要: 为保障电动垂直起降(eVTOL)航空器在城市空域安全自主运行，针对非合作航空器入侵场景，提出了非合作博弈下eVTOL航空器自主避让决策与控制方法。针对具有不同飞行目标及避让意图的航空器，分别构建最优控制模型，并采用连续、混合动作空间表达控制输入；建立了基于非合作微分博弈的多机决策模型，以刻画冲突场景下航空器之间的避让或抢行行为；融合事件触发机制与模型预测控制框架，采用航迹预测-冲突检测-优化计算-控制执行的滚动优化流程，为航空器实时求解单步最优控制指令；采用迭代最优响应算法，逐步逼近非合作微分博弈问题的纳什均衡解，以提高在线计算效率；基于上述模型与算法，在双机对向、同向、交叉冲突场景下，开展了eVTOL航空器的自主避让仿真试验。试验结果表明：当预判入侵机不具备避让意图时，避让效果更优；采用“调速+调向+调高度”的复合机动策略能够使避让安全性提升32%，避让效率提升53%，并且能够减少88%的最大偏移距离；基于迭代最优响应的博弈优化算法单步内平均计算时间小于0.3 s，响应速度快。提出的自主避让决策与控制方法能够使eVTOL航空器在面对非合作目标冲突时，快速生成最优控制策略，从而实现安全、高效的自主避让。Abstract: To ensure the safe autonomous operation of electric vertical take-off and landing (eVTOL) aircraft in urban airspace, an autonomous avoidance decision-making and control method for eVTOL aircrafts under non-cooperative games was proposed for non-cooperative aircraft intrusion scenarios. Optimal control models were constructed respectively for aircraft with different flight goals and avoidance intentions, and continuous and hybrid action spaces were adopted to express control inputs. A multi-aircraft decision-making model based on non-cooperative differential game theory was established to characterize the avoidance or priority-taking behaviors of aircraft in conflict scenarios. An event-triggered mechanism was integrated with a model predictive control framework, and a rolling optimization process of trajectory prediction, conflict detection, optimization calculation, and control execution was adopted to solve the single-step optimal control command for aircraft in real time. An iterative best response algorithm was adopted to progressively approach the Nash equilibrium solution of the non-cooperative differential game to improve online computational efficiency. Based on the proposed models and algorithms, autonomous avoidance simulation experiments of eVTOL aircraft were conducted under head-on, same-direction, and crossing conflict scenarios. Simulation results show that when the intruding aircraft is predicted to have no avoidance intention, the avoidance effect is better. The composite maneuver strategy of "speed adjustment+direction adjustment+altitude adjustment" improves avoidance safety by 32%, increases avoidance efficiency by 53%, and reduces maximum deviation distance by 88%. The average computation time per step of the game optimization algorithm based on iterative best response is less than 0.3 s, and the response speed is fast. The proposed autonomous avoidance decision-making and control method enables eVTOL aircraft to rapidly generate optimal control strategies when facing non-cooperative target conflicts, thereby achieving safe and efficient autonomous avoidance.
-
图 1 基于事件触发MPC的避让决策与控制流程
Figure 1. Avoidance decision and control process based on event-triggered MPC
图 6 试验1中双机轨迹与控制输入变化曲线(对向相遇)
Figure 6. Variation curves of trajectories and control inputs of two aircrafts in experiment 1 (head-on encounter)
图 7 双机间隔曲线(对向相遇)
Figure 7. Curves of separation distance between two aircrafts (head-on encounter)
图 8 控制策略计算时间(对向相遇)
Figure 8. Computational time for control strategy (head-on encounter)
图 9 试验1中双机轨迹与控制输入变化曲线(同向相遇)
Figure 9. Variation curves of trajectories and control inputs of two aircrafts in experiment 1 (overtaking encounter)
图 10 双机间隔曲线(同向相遇)
Figure 10. Curves of separation distance between two aircrafts (overtaking encounter)
图 11 控制策略计算时间(同向相遇)
Figure 11. Computational time of control strategy (overtaking encounter)
图 15 双机间隔曲线(交叉相遇)
Figure 15. Curves of separation distance between two aircrafts (crossing encounter)
表 1 仿真参数设置
Table 1. Simulation parameter settings
参数 取值 时间步长Δt /s 1 预测与优化步数T 5 最低安全间隔d0/m 100 航迹偏离阈值δ/m 1 迭代收敛阈值c 1.0×10-4 飞行高度范围(zmin, zmax)/m (200, 600) 水平速度范围(vminXY, vmaxXY)/(m·s-1) (0, 36.1) 垂直速度范围(vminZ, vmaxZ)/(m·s-1) (0, 10) 航向角范围(Ψmin, Ψmax)/rad (-π, π) 俯仰角范围(θmin, θmax)/rad (-π/6, π/6) 加速度范围(amin, amax)/(m·s-2) (-10, 10) 航向角速率范围(ωmin, ωmax)/(rad·s-1) (-π/6, π/6) 俯仰角速率范围(αmin, αmax)/(rad·s-1) (-π/18, π/18) 代价项权重系数w1~w6 1, 102, 104, 106, 108, 1 注：表中参数值范围可根据实际情况调整。
下载: 导出CSV
表 2 避让效果评价指标
Table 2. Evaluation metrics of avoidance performance
指标 含义 双机间隔/m 任意两架eVTOL在三维空间中的欧氏距离 计算时间/s 单时间步内，从开始求解博弈/跟踪优化问题到求解器返回最优控制输入所用的时间 避让时间/s 从系统首次检测到冲突开始，到冲突完全解除为止所经历的时间 最大横向偏离距离/m 实际航迹相对于参考航迹的偏离程度
下载: 导出CSV
表 3 试验1~4避让效果对比(对向相遇)
Table 3. Comparison of avoidance performances in experiments 1-4 (head-on encounter)
试验 避让时间/ s 最大横向偏移距离/m 平均博弈优化时间/s 平均跟踪优化时间/s 1 113 77.04 0.28 0.03 2 35 134.27 0.24 0.03 3 107 63.46 0.29 0.03 4 50 112.76 0.13 0.03
下载: 导出CSV
表 4 试验1~4避让效果对比(同向相遇)
Table 4. Comparison of avoidance performances in experiments 1-4 (overtaking encounter)
试验 避让时间/ s 最大横向偏移距离/m 平均博弈优化时间/s 平均跟踪优化时间/s 1 111 75.72 0.19 0.03 2 111 121.81 0.18 0.03 3 112 72.11 0.17 0.03 4 111 132.71 0.08 0.03
下载: 导出CSV
表 5 不同控制策略下的避让效果对比
Table 5. Comparison of avoidance performances under different control strategies
控制策略 双机最小间隔/m 避让时间/s 最大横向偏移距离/m 平均博弈优化时间/s 调速 82.52 15 0.00 0.08 调向 76.34 45 788.47 0.14 调高度 77.60 6 99.06 0.14 调速+调向 95.58 13 182.02 0.17 调速+调高度 104.71 10 66.22 0.19 调向+调高度 107.20 14 192.80 0.23 调速+调向+调高度 119.78 8 27.12 0.22
下载: 导出CSV
-
[1] 邓景辉. 电动垂直起降飞行器的技术现状与发展[J]. 航空学报, 2024, 45(5): 47-69.DENG Jing-hui. Technical status and development of electric vertical take-off and landing aircraft[J]. Acta Aeronautica et Astronautica Sinica, 2024, 45(5): 47-69. [2] 张洪海, 邹依原, 张启钱, 等. 未来城市空中交通管理研究综述[J]. 航空学报, 2021, 42(7): 75-99.ZHANG Hong-hai, ZOU Yi-yuan, ZHANG Qi-qian, et al. Future urban air mobility management: Review[J]. Acta Aeronautica et Astronautica Sinica, 2021, 42(7): 75-99. [3] 李诚龙, 屈文秋, 李彦冬, 等. 面向eVTOL航空器的城市空中运输交通管理综述[J]. 交通运输工程学报, 2020, 20(4): 35-54. doi: 10.19818/j.cnki.1671-1637.2020.04.003LI Cheng-long, QU Wen-qiu, LI Yan-dong, et al. Overview of traffic management of urban air mobility (UAM) with eVTOL aircraft[J]. Journal of Traffic and Transportation Engineering, 2020, 20(4): 35-54. doi: 10.19818/j.cnki.1671-1637.2020.04.003 [4] 黄炜, 黄起鹏. 人机共驾控制架构与驾驶权决策研究综述[J]. 交通运输工程学报, 2025, 25(1): 48-65.HUANG Wei, HUANG Qi-peng. Research review of control architecture and driving authority decision-making of driver-automation cooperative driving[J]. Journal of Traffic and Transportation Engineering, 2025, 25(1): 48-65. [5] 董磊, 王琦, 陈曦, 等. 基于运行时保证的DAA系统运行安全保障方法设计[J/OL]. 北京航空航天大学学报, https://doi.org/10.13700/j.bh.1001-5965.2025.0122 .DONG Lei, WANG Qi, CHEN Xi, et al. Design of operational security guarantee method for DAA system based on runtime assurance[J/OL]. Journal of Beijing University of Aeronautics and Astronautics,https://doi.org/10.13700/j.bh.1001-5965.2025.0122 .[6] RIEDEL M. A review of detect and avoid standards for unmanned aircraft systems[J]. Aerospace, 2025, 12(4): 344. doi: 10.3390/aerospace12040344 [7] MCFADYEN A, MEJIAS L. A survey of autonomous vision-based see and avoid for unmanned aircraft systems[J]. Progress in Aerospace Sciences, 2016, 80: 1-17. [8] MANFREDI G, JESTIN Y. Are you clear about "Well Clear"?[C]//IEEE. 2018 International Conference on Unmanned Aircraft Systems (ICUAS). New York: IEEE, 2018: 599-605. [9] 汤新民, 顾俊伟, 刘冰, 等. 低空监视技术及其发展趋势综述[J]. 南京航空航天大学学报, 2024, 56(6): 973-993.TANG Xin-min, GU Jun-wei, LIU Bing, et al. Review on low-altitude surveillance technology and its development trends[J]. Journal of Nanjing University of Aeronautics and Astronautics, 2024, 56(6): 973-993. [10] JOVER J, BERMÚDEZ A, CASADO R. Priority-aware conflict resolution for U-space[J]. Electronics, 2022, 11(8): 1225. doi: 10.3390/electronics11081225 [11] RORIE R C, SMITH C L, MITCHELL M, et al. Assessing helicopter pilots' detect and avoid and collision avoidance performance with ACAS Xr[C]//IEEE. 2023 IEEE/AIAA 42nd Digital Avionics Systems Conference (DASC). New York: IEEE, 2023: 1-10. [12] GUENDEL R E, WU S. Collision avoidance for rotorcraft in urban airspace with ACAS Xr[C]//AIAA. Aviation Forum and Ascend 2025. Reston: AIAA, 2025: 3668. [13] 张学军, 刘法旺, 张祖耀, 等. 低空智能网联体系[J]. 北京航空航天大学学报, 2025, 51(6): 1793-1815.ZHANG Xue-jun, LIU Fa-wang, ZHANG Zu-yao, et al. Overview of low-altitude intelligent networked system[J]. Journal of Beijing University of Aeronautics and Astronautics, 2025, 51(6): 1793-1815. [14] YANG X X, WEI P. Autonomous free flight operations in urban air mobility with computational guidance and collision avoidance[J]. IEEE Transactions on Intelligent Transportation Systems, 2021, 22(9): 5962-5975. doi: 10.1109/TITS.2020.3048360 [15] YANG X X, DENG L S, LIU J, et al. Multi-agent autonomous operations in urban air mobility with communication constraints[C]//AIAA. Scitech 2020 Forum. Reston: AIAA, 2020: 1893. [16] YANG X X, WEI P. Scalable multi-agent computational guidance with separation assurance for autonomous urban air mobility[J]. Journal of Guidance, Control, and Dynamics, 2020, 43(8): 1473-1486. doi: 10.2514/1.G005000 [17] BERTRAM J, WEI P, ZAMBRENO J. A fast Markov decision process-based algorithm for collision avoidance in urban air mobility[J]. IEEE Transactions on Intelligent Transportation Systems, 2022, 23(9): 15420-15433. doi: 10.1109/TITS.2022.3140724 [18] WU P C, YANG X X, WEI P, et al. Safety assured online guidance with airborne separation for urban air mobility operations in uncertain environments[J]. IEEE Transactions on Intelligent Transportation Systems, 2022, 23(10): 19413-19427. doi: 10.1109/TITS.2022.3163657 [19] KATZ S M, ALVAREZ L E, OWEN M, et al. Collision risk and operational impact of speed change advisories as aircraft collision avoidance maneuvers[C]//AIAA. Aviation 2022 Forum. Reston: AIAA, 2022: 3824. [20] ZHANG N, ZHANG M C, LOW K H. 3D path planning and real-time collision resolution of multirotor drone operations in complex urban low-altitude airspace[J]. Transportation Research Part C: Emerging Technologies, 2021, 129: 103123. doi: 10.1016/j.trc.2021.103123 [21] QUAN Q, FU R, CAI K Y. Practical control for multicopters to avoid non-cooperative moving obstacles[J]. IEEE Transactions on Intelligent Transportation Systems, 2022, 23(8): 10839-10857. doi: 10.1109/TITS.2021.3096558 [22] LI S M, CHENG X C, HUANG X D, et al. Cooperative conflict detection and resolution and safety assessment for 6G enabled unmanned aerial vehicles[J]. IEEE Transactions on Intelligent Transportation Systems, 2023, 24(2): 2183-2198. [23] CHAMBERLAIN J, CONSIGLIO M, MUÑOZ C, et al. Assistive detect and avoid technology in urban air mobility environments[C]//IEEE. 2024 AIAA DATC/IEEE 43rd Digital Avionics Systems Conference (DASC). New York: IEEE, 2024: 1-7. [24] CHEN J D, LIU Y G, ZHANG Y, et al. Conflict detection and resolution strategy for eVTOLs in low-altitude urban environments based on the geodetic coordinate system[J]. IEEE Transactions on Aerospace and Electronic Systems, 2024, 60(6): 8823-8838. doi: 10.1109/TAES.2024.3435632 [25] 郝鹏. 面向UAM系统的eVTOL飞行器避障路径规划算法研究[D]. 成都: 西华大学, 2022.HAO Peng. Obstacle avoidance path planning of eVTOL aircraft for UAM system algorithm research[D]. Chengdu: Xihua University, 2022. [26] DENIZ S, WANG Z B. Autonomous conflict resolution in urban air mobility: a deep multi-agent reinforcement learning approach[C]//AIAA. Aviation Forum and Ascend 2024. Reston: AIAA, 2024: 4005. [27] 张康, 汤新民, 顾俊伟. 基于风险意识的eVTOL自主避让[J/OL]. 航空学报, 2025, https://link.cnki.net/urlid/11.1929.V.20250720.0733.006 .ZHANG Kang, TANG Xin-min, GU Jun-wei. Risk-aware autonomous avoidance for eVTOL[J/OL]. Acta Aeronautica et Astronautica Sinica, 2025,https://link.cnki.net/urlid/11.1929.V.20250720.0733.006 .[28] CAO X Y, NING X, LIU S Y, et al. Spacecraft intelligent orbital game technology: A review[J]. Chinese Journal of Aeronautics, 2025, 38(6): 103480. doi: 10.1016/j.cja.2025.103480 [29] 秦家虎, 马麒超, 李曼, 等. 多智能体协同研究进展综述: 博弈和控制交叉视角[J]. 自动化学报, 2025, 51(3): 489-509.QIN Jia-hu, MA Qi-chao, LI Man, et al. Recent advances on multi-agent collaboration: A cross-perspective of game and control theory[J]. Acta Automatica Sinica, 2025, 51(3): 489-509. [30] 曲大义, 李奥迪, 张智, 等. 多车响应的网联自动驾驶纵横向协同控制方法[J]. 交通运输工程学报, 2025, 25(4): 281-295. doi: 10.19818/j.cnki.1671-1637.2025.04.020QU Da-yi, LI Ao-di, ZHANG Zhi, et al. Multi-vehicle responsive longitudinal and lateral cooperative control method for networked autonomous driving[J]. Journal of Traffic and Transportation Engineering, 2025, 25(4): 281-295. doi: 10.19818/j.cnki.1671-1637.2025.04.020 [31] 衣鹏, 潘越, 王文远, 等. 基于博弈论的多车智能驾驶交互决策综述[J]. 控制与决策, 2023, 38(5): 1159-1175.YI Peng, PAN Yue, WANG Wen-yuan, et al. A review on interactive decision-making of multi-vehicle autonomous driving with a game theoretical perspective[J]. Control and Decision, 2023, 38(5): 1159-1175. -
