A dynamic collision avoidance method for UAVs using value iteration
-
摘要: 针对无人机飞行冲突自主解脱需要，提出了一种基于值迭代方法的马尔可夫决策过程优化模型。首先构建了值迭代动态避撞模型，实现无人机的实时安全避撞；然后针对空域的复杂性和不确定性问题，构建了涵盖两机相对高度、本机与入侵机的垂直速度、历史动作及时间等参数的精细化状态空间集；之后通过构建多因素动态成本函数，综合考虑冲突风险、最接近时间等因素进行动作判断，减少了无人机避撞时的不必要机动操作；最后提出通过引入自适应双层概率融合机制，解决传统确定性决策在复杂动态环境中的脆弱性问题，提高决策的鲁棒性。仿真试验结果表明：提出的动态避撞方法在3个仅考虑动态入侵机的冲突场景中可以实现无人机的安全避撞，两机最终相对高度分别为152.5、188.0、143.7 m；在同时考虑静态障碍物和动态入侵机的混合冲突场景中，本机与静态障碍物的最小垂直相对高度为174.7 m，两机的垂直相对高度为230.7 m，可以保证无人机安全飞行；与动态窗口法方法相比，4个场景下本机执行基于值迭代的避撞策略后，平均过度位置调整高度减少了62.4%，平均不必要的动作切换次数减少了88%。提出的基于值迭代的动态规划方法解决无人机避撞场景下的马尔可夫决策过程问题是可行的，无人机可以实现安全避撞。Abstract: A Markov decision process (MDP) optimization model based on value iteration was proposed for the needs of autonomous conflict resolution of unmanned aerial vehicles. A value iteration-based dynamic collision avoidance model was first constructed to achieve real-time safe collision avoidance. To address the complexity and uncertainty of airspace, a refined state space was formulated, incorporating parameters such as relative altitude between two aircraft, vertical speeds of ownship and intruder, historical actions, and time. A multi-factor dynamic cost function was designed to integrate conflict risk and time to closest approach for action judgement, thereby reducing unnecessary maneuvers during collision avoidance. An adaptive two-layer probabilistic fusion mechanism was introduced to address the vulnerability of traditional deterministic decision-making in complex dynamic environments and improve decision robustness. The results indicate that the proposed dynamic collision avoidance method can achieve safe collision avoidance in three conflict scenarios considering only dynamic intruders, and the final vertical relative heights between two aircraft are 152.5, 188.0, and 143.7 m, respectively. In the mixed conflict scenario considering both static obstacles and dynamic intruders, the minimum vertical relative height between the ownship and static obstacles is 174.7 m, and the vertical relative height between two aircraft is 230.7 m, which ensures the safe flight of unmanned aerial vehicle. Compared with the dynamic window approach (DWA) method, after the ownship executes the collision avoidance strategy based on value iteration in four scenarios, the average excessive altitude adjustment is reduced by 62.4%, and the average number of unnecessary action switches is reduced by 88%. It is indicated that the proposed dynamic programming method based on value iteration is feasible to solve the Markov decision process problem in collision avoidance scenarios, and the unmanned aerial vehicle can achieve safe collision avoidance.
-
图 4 基于值迭代的动态避撞模型构建流程
Figure 4. Construction flow of value-iteration-based dynamic collision-avoidance model
图 8 无交点航线避撞
Figure 8. Collision avoidance for aircraft on non-intersecting trajectories
图 9 考虑静态障碍物的入侵机爬升航线避撞
Figure 9. Collision avoidance for intruder aircraft's climb trajectory in the presence of static obstacles
图 10 同高度相向航线避撞
Figure 10. Collision avoidance for head-on aircraft at the same altitude
图 12 使用经典值迭代方法考虑静态障碍物的入侵机爬升航线避撞
Figure 12. Collision avoidance for intruder aircraft's climb trajectory in the presence of static obstacles using the classical value iterative method
图 14 两种方法避撞性能对比
Figure 14. Performance comparison of the two collision-avoidance methods
表 1 动作空间
Table 1. Action space
动作 垂直速度/(m·s-1) 垂直加速度 前一状态 最大 最小 COC ∞ -∞ 0 ALL DES ∞ -8 0.25g COC CL 8 -∞ 0.25g COC
下载: 导出CSV
表 2 离散状态变量
Table 2. Discrete state variable
状态变量 离散范围 离散尺度 离散值数量 hr -300、-270、...、300 m 30 m 21 v1 -8、-7、...、8 m·s-1 1 m·s-1 17 v2 -8、-7、...、8 m·s-1 1 m·s-1 17 ap COC、DES、CL 3 d 1、2、3 s 1 s 3 t 1、2、...、45 s 1 s 45
下载: 导出CSV
表 4 动作切换成本
Table 4. Action switching cost
切换动作情况 C2(a, ap)成本 a=ap 0.00 a≠ap 0.01 a≠ap且a不等于COC且ap不等于COC 0.06
下载: 导出CSV
表 5 基于高度范围的成本
Table 5. Altitude-based cost
相对高度范围/m C3(hr)成本 137≤hr -0.30 61≤hr＜137 -0.01 30≤hr＜61 0.00 15≤hr＜30 0.05 hr＜15 0.15
下载: 导出CSV
表 6 基于与冲突点的时间和距离的成本
Table 6. Time-to-collision based cost
决策时机 C4(hr, a, tc)成本 a不等于COC，tc＞30 0.25 a不等于COC，20＜tc≤30 0.10 a等于COC，hr＜61，tc＜10 0.15
下载: 导出CSV
表 7 危险程度分级
Table 7. Risk classification
危险级别 相对高度范围/m 安全 137≤hr 较安全 61≤hr＜137 警戒 30≤hr＜61 危险 15≤hr＜30 极危险 hr＜15
下载: 导出CSV
表 8 经典值迭代方法试验参数设置
Table 8. Experimental parameter settings for the classical value iterative method
试验设置 状态空间规模/个 垂直速度/ (m·s-1) 垂直加速度 成本函数/ 10-2 参数 2 457 945 小 大 COC 0.00 COC 0.1 -8 8 DES 0.25g DES 5.6 CL 0.25g CL 5.6
下载: 导出CSV
表 9 值迭代方法4个场景相关结果
Table 9. Results of value iteration algorithm in four scenarios
场景 场景1 场景2 场景3 场景4 最终相对高度/m 152.5 188.0 143.7 230.7 动作切换次数 5 3 2 2
下载: 导出CSV
表 10 DWA方法4个场景相关结果
Table 10. Results of the DWA method in four scenarios
场景 场景1 场景2 场景3 场景4 最终相对高度/m 214.4 247.0 182.8 350.5 动作切换次数 31 18 31 20
下载: 导出CSV
-
