Reliability-oriented unmanned aerial vehicle nest location optimization method for smart city management inspection
Article Text (Baidu Translation)
-
摘要: 为实现基于固定机巢的城管事件无人机自动巡查，降低机巢和无人机失效对效率与稳定性的影响，研究了基于多层级备援机制的固定机巢可靠性选址-分配问题；考虑任务点差异化巡查频率和固定机巢服务半径约束，构建了以机巢建设与运行总成本最小为目标的混合整数规划模型；提出基于拉格朗日松弛的混合算法，通过松弛选址-分配耦合约束，将原问题分解为机巢选址与多层级任务分配2个子问题精确求解以获得紧下界，设计覆盖增益驱动的选址修复算法生成可行上界，提出了基于邻域搜索的上界改进算法以加速收敛。研究结果表明：在小、中规模算例上，所提算法相较Gurobi求解器计算时间缩短57.56%~88.86%，大规模问题亦可在较短时间内给出高质量解；多层级冗余显著降低系统成本，以大连市中山区为例，3层冗余配置将总成本从72.36万元降至43.72万元，降幅约为39.59%，配置3层以上冗余机巢的边际收益显著减弱；随着机巢服务半径增大，总成本与建设成本先下降后趋于稳定，巡查成本基本不变；机巢采购单价与总成本、建设成本、巡检成本及人工巡检成本呈正相关，与机巢数量呈负相关；无人机单位飞行价格与总成本、建设成本和巡检成本近线性正相关，对人工巡检成本影响不显著。Abstract: To enable automatic inspection by unmanned aerial vehicles for urban management events based on fixed nests and to mitigate the impact of nest and unmanned aerial vehicle failures on efficiency and stability, the reliability-oriented fixed nest location-allocation problem with multi-level backup mechanisms was investigated. The differentiated inspection frequencies of task points and service radius constraints of fixed nests were considered, and a mixed integer programming model was formulated with the objective of minimizing the total cost of nest construction and operation. A hybrid algorithm based on Lagrangian relaxation was proposed. The original problem was decomposed into two subproblems, i.e., nest location and multi-level task allocation, by relaxing the location-allocation coupling constraints, and they were solved exactly to obtain a tight lower bound. A coverage gain-driven location repair algorithm was designed to generate feasible upper bounds. An upper bound improvement algorithm based on neighborhood search was proposed to accelerate convergence. Research results show that, for small-scale and medium-scale instances, the proposed algorithm reduces computation time by 57.56%–88.86% compared with Gurobi, while producing high-quality solutions for large-scale cases within short runtimes. Multi-level redundancy significantly reduces system costs. In the case of Zhongshan District of Dalian, the three-level redundancy configuration reduces the total cost from 723 600 CNY to 437 200 CNY, a reduction of approximately 39.59%. The marginal benefits of configuring nests with more than three levels of redundancy diminish significantly. As the nest service radius increases, total and construction costs decline and then stabilize, with inspection costs remaining nearly unchanged. Unit cost of nest procurement is positively correlated with total, construction, inspection, and manual inspection costs and negatively correlated with the number of nests. Unmanned aerial vehicle unit flight cost shows a near-linear positive correlation with total, construction, and inspection costs but has no significant impact on manual inspection cost.
-
图 1 考虑机巢失效的选址分配网络
Figure 1. Location-allocation network model considering UAV nest failures
表 1 城管巡查重点区域示例
Table 1. Example of key areas for urban management patrol
属性 信息 编号 2 中心位置 经纬度（121.614 6° E，38.914 3° N） 土地类型 商业密集区 土地面积 长度为800 m、宽度为600 m 巡查目标 占道经营、垃圾堆放、高楼消防、道路缺陷、违规搭建等 巡查建议 周期巡查 巡查频率 每日2次 预计时间 30 min
下载: 导出CSV
表 2 算例计算结果
Table 2. Results of the case study
|L| p=0.2 p=0.4 建设成本/元 巡检成本/元 总成本/元 减小比例/% 建设成本/元 巡检成本/元 总成本/元 减小比例/% 1 140 000 583 589.69 723 589.69 120 000 1 045 150.68 1 165 150.68 2 220 000 244 856.50 464 856.50 35.76 220 000 522 238.55 742 238.55 36.30 3 240 000 197 152.96 437 152.96 39.59 300 000 318 732.27 618 732.27 46.90 4 240 000 196 557.38 436 557.38 39.67 340 000 252 554.99 592 554.99 49.14 5 240 000 196 557.38 436 557.38 39.67 340 000 259 423.45 589 423.45 49.41 6 240 000 196 557.38 436 557.38 39.67 340 000 248 918.71 588 918.71 49.46
下载: 导出CSV
表 3 算法对比结果
Table 3. Comparison of algorithms
算例
规模p 本文算法 Gurobi 邻域搜索算法 上界/元 下界/元 间隙1/% 间隙2/% 计算
时间/s最优值/元 计算
时间/s最优值/元 计算
时间/s43 0.05 105 184.15 104 318.98 0.82 0.00 15.40 105 184.15 45.36 109 337.47 14.37 0.10 114 958.47 114 393.89 0.49 0.00 23.89 114 958.47 47.68 115 282.68 15.35 0.20 131 409.26 130 264.34 0.87 0.00 24.22 131 409.26 52.19 131 409.26 15.87 0.40 199 953.00 199 016.53 0.46 0.00 16.84 199 953.00 48.87 201 353.17 12.77 117 0.05 341 427.73 339 216.62 0.65 0.12 140.04 341 019.17 874.98 346 427.35 89.30 0.10 374 218.52 372 235.16 0.53 0.00 157.28 374 218.52 1 149.77 377 794.63 72.04 0.20 437 152.96 434 805.52 0.54 0.00 112.66 437 140.04 1 284.42 442 392.88 65.54 0.40 618 732.27 615 276.77 0.58 0.00 114.97 618 732.27 1 422.75 623 721.91 66.88 285 0.05 802 045.38 778 385.04 2.95 521.33 3 600.00 818 810.07 430.02 0.10 879 347.98 861 936.89 1.98 487.25 3 600.00 887 876.48 433.98 0.20 1 021 561.95 1 003 963.52 1.72 267.25 3 600.00 1 031 273.42 411.06 0.40 1 466 341.79 1 444 221.75 1.51 444.06 3 600.00 1 483 952.38 402.59 注：“间隙1”表示所提算法计算得到的上下界之间的相对误差，“间隙2”表示所提算法获得的上界与Gurobi求解器获得的最优解之间的相对误差，加粗的结果表示算法横向对比中的最优表现。
下载: 导出CSV
-
