Computation model of standing-passenger density in urban rail transit carriage
Article Text (Baidu Translation)
-
摘要: 为科学合理地确定城市轨道交通车厢立席密度, 从立席乘客舒适度的角度探讨了合理立席密度对舒适度的影响。通过问卷调查和实地测量进行分析和量化, 确定了空间舒适度和车厢微环境2个主要因素, 基于线性加权法和顾客赋权法将2个因素结合构建了静态舒适度评价模型。考虑到站立时长对舒适度的影响, 类比疲劳程度指标对静态舒适度评价模型进行修正, 通过问卷调查验证时间折减因子并标定参数, 构建了基于立席密度的广义舒适度评价模型, 通过广义舒适度评价模型反推得到合理立席密度求解模型, 并对北京地铁4号线-大兴线进行舒适度评价。分析结果表明: 舒适度可以及时、准确地反映立席密度的变化和影响, 借助舒适度评价结果可以改善运营线路的服务水平; 北京地铁4号线-大兴线满足舒适等级、设计等级和超员等级的合理立席密度分别为3.1、4.2、4.7人·m-2, 美国车辆设计定员的相应立席密度分别为3.0、4.0、6.0人·m-2, 两者基本相当, 且计算结果与调研结果相符, 因此, 模型可作为规划设计中确定合理立席密度的依据。Abstract: To determine a scientific and reasonable standing-passenger density in urban rail transit carriage, the impact of standing-passenger density on comfort was studied in the perspective of standing passenger's comfort. Through analyzing and quantizing the data collected from questionnaires and field measurements, two main factors namely spatial congestion and carriage microenvironment were obtained.Based on the means of linear weighting method and customer empowerment method, a static comfort evaluation model was built by combining the 2factors.Considering the effect of long-time standing on comfort, and comparing to the fatigue index, the static comfort evaluation model was modified.A questionnaire survey was conducted to verify the time reduction factor and determine the parameters. A standing-passenger density-based generalized comfort evaluation model was built.Based on the generalized comfort evaluationmodel, a reasonable standing-passenger density model was proposed by using backstepping approach.Based on the built model, the Line 4of the Beijing Subway-Daxing Line was used for comfort evaluation.Analysis result indicates that the comfort evaluation can reflect the change of standing-passenger density timely and accurately, and the comfort evaluating result can help improving the service level of urban transit.The reasonable standing-passenger densities of Line4 of the Beijing Subway-Daxing Line meeting the comfortable level, designed level, and overcrowding level are 3.1, 4.2, 4.7person·m-2, respectively, the calculated densities are corresponding to 3.0, 4.0, 6.0person·m-2 of vehicle design capacity of American, and also consistent with the survey result, so the model can be used to determine the standing-passenger density in the planning and design of urban transit.
-
图 2 立席密度与温度、湿度的关系
Figure 2. Relationship among standing-passenger density, temperature, and humidity
图 3 区间PM2.5质量浓度与立席密度
Figure 3. PM2.5concentration and standing-passenger density of intervals
图 4 CO2质量浓度与立席密度关系
Figure 4. Relationship between standing-passenger density and CO2 concentration
图 7 立席密度与折减系数的关系
Figure 7. Relationship between reduction coefficient and standing-passenger density
图 8 不同舒适度评价模型的评价结果
Figure 8. Evaluation results of different comfort evaluation models
表 1 调研结果
Table 1. Investigation result
表 2 不同线路平均旅行时间
Table 2. Average travel times of different lines
表 3 不同舒适度等级的合理立席密度
表 4 不同标准的立席密度比较
Table 4. Comparison of standing-passenger densities in different standards
-
[1] 卢春霞. 拥挤人群中的挤压分析[J]. 交通运输系统工程与信息, 2007, 7(2): 98-103.LU Chun-xia. The analysis of compressed force in crowds[J]. Journal of Transportaton Systems Engineering and Information Technology, 2007, 7(2): 98-103. (in Chinese). [2] 刘晓琴, 李剑峰, 李伟. 人群密度与预警管理的研究[J]. 安全, 2009, 30(4): 19-22.LIU Xiao-qin, LI Jian-feng, LI Wei. Crowd density and advance warning management[J]. Safety, 2009, 30(4): 19-22. (in Chinese). [3] 冉丽君, 刘茂. 人群密度对人群拥挤事故的影响[J]. 安全与环境学报, 2007, 7(4): 135-138.RAN Li-jun, LIU Mao. Effects of crowded people density on crushing fatalities[J]. Journal of Safety and Environment, 2007, 7(4): 135-138. (in Chinese). [4] 祁国梁. 城市轨道交通车厢立席密度时空分布规律研究[D]. 北京: 北京交通大学, 2009.QI Guo-liang. Study on the space and time distribution of standing-passenger density in carriage of urban rail transit[D]. Beijing: Beijing Jiaotong University, 2009. (in Chinese). [5] 赵亮. 城市轨道交通立席密度研究[D]. 北京: 北京交通大学, 2009.ZHAO Liang. Study on density of standing passengers in urban rail transit[D]. Beijing: Beijing Jiaotong University, 2009. (in Chinese). [6] 沈景炎. 关于车辆定员与拥挤度的探析[J]. 都市快轨交通, 2007, 20(5): 14-18.SHEN Jing-yan. On the carriage passenger capacity and the crowdedness involved[J]. Urban Rapid Rail Transit, 2007, 20(5): 14-18. (in Chinese). [7] 章云泉. 城市轨道交通容量的影响因素研究[J]. 城市轨道交通研究, 1999, 2(4): 26-29. https://www.cnki.com.cn/Article/CJFDTOTAL-GDJT199904012.htmZHANG Yun-quan. On the affective factors over urban mass transit capacity[J]. Urban Mass Transit, 1999, 2(4): 26-29. (in Chinese). https://www.cnki.com.cn/Article/CJFDTOTAL-GDJT199904012.htm [8] 吴奇兵, 陈峰, 刘畅. 基于舒适性的轨道交通车厢合理立席密度研究[J]. 综合运输, 2014(4): 53-58.WU Qi-bing, CHEN Feng, LIU Chang. A study on reasonable density of standing passenger based on comfort[J]. Comprehensive Transportation, 2014(4): 53-58. (in Chinese). [9] 倪纯双, 王悦明. 浅析平稳性指标和舒适度指标[J]. 铁道机车车辆, 2003, 23(6): 1-3. https://www.cnki.com.cn/Article/CJFDTOTAL-TDJC200306000.htmNI Chun-shuang, WANG Yue-ming. A brief discussion for ride index and comfort[J]. Railway Locomotive and Car, 2003, 23(6): 1-3. (in Chinese). https://www.cnki.com.cn/Article/CJFDTOTAL-TDJC200306000.htm [10] TIRACHINI A, HENSHER D A, ROSE J M. Crowding in public transport systems: effects on users, operation and implications for the estimation of demand[J]. Transportation Research Part A: Policy and Practice, 2013, 53: 36-52. [11] 陈祥. 高速铁路客车乘坐舒适度综合评价模型研究[D]. 成都: 西南交通大学, 2010.CHEN Xiang. Research of comprehensive evaluation model on riding comfort of high-speed train[D]. Chengdu: Southwest Jiaotong University, 2010. (in Chinese). [12] 夏朝侠. 高速列车乘坐舒适度评价方法的研究[D]. 沈阳: 东北大学, 2010.XIA Zhao-xia. Research of evaluation method on riding comfort of high-speed train[D]. Shenyang: Northeastern University, 2010. (in Chinese). [13] 樊玲, 冯炼. 利用"相对热流指标"对地铁系统设计温度的探讨[J]. 城市轨道交通研究, 2002, 5(1): 50-52.FAN Ling, FENG Lian. On design temperature of metro system by using relative warmth index[J]. Urban Mass Transit, 2002, 5(1): 50-52. (in Chinese). [14] 茅艳. 人体热舒适气候适应性研究[D]. 西安: 西安建筑科技大学, 2007.MAO Yan. Study on climate adaptability of human beings to thermal comfort in China[D]. Xi'an: Xi'an University of Architecture and Technology, 2007. (in Chinese). [15] 李新, 石建屏, 魏锡文, 等. 室内空气质量指数评价模式的研究[J]. 环境保护科学, 2007, 33(6): 5-7, 11. https://www.cnki.com.cn/Article/CJFDTOTAL-HJBH200706003.htmLI Xin, SHI Jian-ping, WEI Xi-wen, et al. Study on the index mode of indoor air quality evaluation[J]. Environmental Protection Science, 2007, 33(6): 5-7, 11. (in Chinese). https://www.cnki.com.cn/Article/CJFDTOTAL-HJBH200706003.htm [16] 刘建国, 刘洋. 室内空气中CO2的评价作用与评价标准[J]. 环境与健康杂志, 2005, 22(4): 303-305.LIU Jian-guo, LIU Yang. The role and the standard of the evaluation of CO2 indoor[J]. Journal of Environment and Health, 2005, 22(4): 303-305. (in Chinese). [17] 尹聪聪, 蒲琪, 李素莹. 基于乘客感知的城市轨道交通客运服务质量评价指标研究[J]. 城市轨道交通研究, 2014, 17(6): 78-83, 89. https://www.cnki.com.cn/Article/CJFDTOTAL-GDJT201406027.htmYIN Cong-cong, PU Qi, LI Su-ying. On the evaluation index of service quality on urban rail transit based on passenger perception[J]. Urban Mass Transit, 2014, 17(6): 78-83, 89. (in Chinese). https://www.cnki.com.cn/Article/CJFDTOTAL-GDJT201406027.htm [18] 周艳芳, 周磊山. 城市轨道交通乘客满意度评价体系的构建[J]. 都市快轨交通, 2007, 20(5): 25-28.ZHOU Yan-fang, ZHOU Lei-shan. Establishing assessment system about passenger satisfaction indices in urban rail transit[J]. Urban Rapid Rail Transit, 2007, 20(5): 25-28. (in Chinese). [19] 张家玲, 易思蓉. 疲劳时间法在线路平面舒适度参数选择中的应用[J]. 铁道标准设计, 2007(5): 27-29.ZHANG Jia-ling, YI Si-rong. The application of fatigue time method on the comfort parameter selection of lines'plane[J]. Railway Standard Design, 2007(5): 27-29. (in Chinese). [20] 徐智慧, 甘军霞, 李春清. 动车组合理开行距离研究[J]. 兰州交通大学学报, 2008, 27(1): 83-85.XU Zhi-hui, GAN Jun-xia, LI Chun-qing. Research on reasonable operation distance of train-set[J]. Journal of Lanzhou Jiaotong University, 2008, 27(1): 83-85. (in Chinese). [21] 朱剑月, 朱良光, 周劲松, 等. 地铁车辆运行舒适度与平稳性评价[J]. 城市轨道交通研究, 2007, 10(6): 28-31. https://www.cnki.com.cn/Article/CJFDTOTAL-GDJT200706010.htmZHU Jian-yue, ZHU Liang-guang, ZHOU Jin-song, et al. Evaluation of riding comfort and stability index[J]. Urban Mass Transit, 2007, 10(6): 28-31. (in Chinese). https://www.cnki.com.cn/Article/CJFDTOTAL-GDJT200706010.htm [22] 北京交通发展研究中心. 2013北京市交通发展年度报告[R]. 北京: 北京交通发展研究中心, 2013. Beijing Transportation Research Center. 2013 Beijing transport annual report[R]. Beijing: Beijing Transportation Research Center, 2013. (in Chinese). -
