Longitudinal movement characteristics and rational restraint systems of long-span railway suspension bridges under train load
Article Text (Baidu Translation)
-
摘要: 为研究列车荷载作用下大跨度铁路悬索桥纵向运动特性并明确合理纵向约束体系，通过现场试验分析了列车过桥时梁端纵向运动响应；以某在役铁路悬索桥为研究对象，构建了纵向动力精细化分析模型，与实测结果进行对比验证其可靠性；在此基础上建立了不同纵向约束体系分析模型，采用瞬态动力分析法对比了列车荷载作用下梁端纵向振动响应及关键连接构件受力规律。研究结果表明：采用单塔固定约束时，列车过桥引起的活动支座纵向位移峰值为9.80 mm，因支座摩阻力与梁轨相互作用影响，列车通过后支座未能迅速复位；所建立的纵向动力模型可精确地刻画列车过桥全过程支座纵向位移的动态变化，峰值位移与试验结果吻合良好；增加纵向约束刚度与附加阻尼均能有效抑制加劲梁纵向振动，纵飘体系下梁端纵向位移幅值达79.2 mm，设置中央扣后减小至43.1 mm，加设阻尼器进一步降至30.5 mm；中央扣能显著改善短吊索受力，未设中央扣时吊索最大弯曲应力为23.57 MPa，设置后降至8.03 MPa，降幅达65.9%；中央扣应力幅随纵向约束刚度增加呈增大趋势，增设阻尼器或考虑支座摩阻力后分别为191.59 MPa与205.92 MPa；过强的纵向约束刚度将导致短吊索弯曲应力倍增，引起中央扣应力集中，严重威胁跨中连接构件的服役寿命；大跨度铁路悬索桥纵向约束体系设计应综合考虑梁端纵向位移控制与短吊索的受力均衡，避免因纵向约束刚度过大引起构件不利内力集中。研究成果可为大跨度铁路悬索桥纵向约束体系的设计优化与健康运维提供参考。Abstract: To investigate the longitudinal movement characteristics of long-span railway suspension bridges under train loads and determine a rational longitudinal restraint system, a field test was conducted to analyze the longitudinal movement responses at the girder ends during train passage. A refined longitudinal dynamic analysis model was developed based on an in-service railway suspension bridge, and its reliability was verified by comparing with measured results. Based on this, analysis models of different longitudinal restraint systems were established, and a transient dynamic analysis method was adopted to compare the longitudinal vibration responses at the girder ends and the mechanical behaviors of key connecting components under train loads. The results indicate that when a single-tower fixed restraint is adopted, the peak longitudinal displacement of the movable bearing caused by train passage is 9.80 mm. Due to the influence of bearing friction and girder-rail interaction, the bearing fails to reset rapidly after the train passes. The developed longitudinal dynamic model accurately characterizes the dynamic variations of longitudinal bearing displacement during the whole process of train passage, and the peak displacement agrees well with the test results. Increasing longitudinal restraint stiffness and adding supplemental damping can both effectively suppress the longitudinal vibration of the stiffening girder. Under the floating system, the longitudinal displacement amplitude at the girder end reaches 79.2 mm, which decreases to 43.1 mm after the central buckle is set and further decreases to 30.5 mm after the damper is added. The central buckle significantly improves the mechanical behaviors of short hangers. Without the central buckle, the maximum bending stress of the hanger is 23.57 MPa, which decreases to 8.03 MPa after installation, with a reduction of 65.9%. The stress amplitude of the central buckle shows an increasing trend with the increase of longitudinal restraint stiffness and reaches 191.59 MPa and 205.92 MPa after adding dampers or considering bearing friction, respectively. Excessive longitudinal restraint stiffness doubles the bending stress of short hangers, causes stress concentration in the central buckle, and seriously threatens the service life of mid-span connecting components. The design of longitudinal restraint systems for long-span railway suspension bridges should comprehensively consider the longitudinal displacement control at the girder ends and the mechanical balance of short hangers to avoid unfavorable internal force concentration of components caused by excessive longitudinal restraint stiffness. The research results can provide a reference for the design optimization and healthy operation and maintenance of longitudinal restraint systems for long-span railway suspension bridges.
-
图 1 某大跨度铁路悬索桥立面布置及约束体系
Figure 1. Elevation layout and restraint system of long-span railway suspension bridge
图 3 行车试验测点布置（下行线单侧布置）
Figure 3. Measurement point layout for train-passing test (single-side arrangement on down track)
图 6 列车过桥支座纵向位移时程曲线
Figure 6. Time history curves of bearing longitudinal displacement during train passage
图 7 不同行车速度下支座及伸缩缝纵向位移幅值
Figure 7. Amplitude of longitudinal displacement of bearing and expansion joint width under different train speeds
图 8 铁路悬索桥纵向动力精细化分析模型
Figure 8. Refined longitudinal dynamic analysis model of railway suspension bridge
图 9 基于环境激励的结构竖向振动响应及频谱特性
Figure 9. Vertical vibration responses and spectral characteristics of structure under ambient excitation
图 10 精细化模型与实测动态响应对比
Figure 10. Comparison of dynamic responses between refined model and field measurements
图 14 吊索的纵向缆梁位移差
Figure 14. Longitudinal displacement differences of cable beam in hangers
图 17 不同约束体系下短吊索弯曲应力
Figure 17. Bending stresses of short hangers under different restraint systems
图 18 不同纵向约束体系下中央扣应力
Figure 18. Stresses of central buckle under different restraint systems
表 1 铁路悬索桥模态特性对比
Table 1. Comparison of modal characteristics of railway suspension bridge
模态类型 振型 自振频率/Hz 相对误差/% FEM计算值 实测结果 主梁对称横弯
0.163 0.177 7.7 主梁对称竖弯
0.243 0.252 3.5 主梁反对称竖弯
0.308 0.342 9.9 主梁反对称横弯
0.410 0.439 6.6 主缆相向振动
0.472 0.506 6.7 主梁纵向及竖弯
0.520 0.542 4.0
下载: 导出CSV
-
[1] 周智辉, 刘瑞涛, 朱志辉, 等. 基于ANSYS-MATLAB联合仿真的大跨铁路悬索桥行车分析[J]. 交通运输工程学报, 2021, 21(2): 117-128. doi: 10.19818/j.cnki.1671-1637.2021.02.010ZHOU Zhi-hui, LIU Rui-tao, ZHU Zhi-hui, et al. Train passing analysis on large-span railway suspension bridge based on ANSYS-MATLAB co-simulation[J]. Journal of Traffic and Transportation Engineering, 2021, 21(2): 117-128. doi: 10.19818/j.cnki.1671-1637.2021.02.010 [2] 唐贺强, 徐恭义, 刘汉顺. 五峰山长江大桥主桥总体设计[J]. 桥梁建设, 2020, 50(6): 1-7.TANG He-qiang, XU Gong-yi, LIU Han-shun. Overall design of main bridge of Wufengshan Changjiang River Bridge[J]. Bridge Construction, 2020, 50(6): 1-7. [3] 刘伟, 陈克坚, 游励晖. 虎跳峡金沙江大桥方案研究[J]. 铁道工程学报, 2013(6): 47-51.LIU Wei, CHEN Ke-jian, YOU Li-hui. Research on selections of bridge site and type of Hutiaoxia Jinsha River Bridge[J]. Journal of Railway Engineering Society, 2013(6): 47-51. [4] 李永乐, 钱逸哲, 朱金, 等. 随机风、车流联合作用下大跨公路悬索桥纵向振动特性研究[J]. 中国公路学报, 2021, 34(4): 93-104.LI Yong-le, QIAN Yi-zhe, ZHU Jin, et al. Longitudinal vibration characteristics of a long-span highway suspension bridge under stochastic wind and traffic loads[J]. China Journal of Highway and Transport, 2021, 34(4): 93-104. [5] 万田保, 李松林. 大跨度铁路悬索桥纵向位移特征及纵向支承要求[J]. 桥梁建设, 2020, 50(4): 29-35.WAN Tian-bao, LI Song-lin. Longitudinal displacement characteristics and longitudinal supporting requirements for long-span railway suspension bridge[J]. Bridge Construction, 2020, 50(4): 29-35. [6] GUO T, LIU J, ZHANG Y F, et al. Displacement monitoring and analysis of expansion joints of long-span steel bridges with viscous dampers[J]. Journal of Bridge Engineering, 2015, 20(9): 04014099. doi: 10.1061/(ASCE)BE.1943-5592.0000701 [7] GUO T, LIU J, HUANG L Y. Investigation and control of excessive cumulative girder movements of long-span steel suspension bridges[J]. Engineering Structures, 2016, 125: 217-226. doi: 10.1016/j.engstruct.2016.07.003 [8] 杨东辉, 顾海伦, 伊廷华, 等. 大跨悬索桥加劲梁纵向约束性能诊断与评估进展[J]. 中国公路学报, 2025, 38(11): 112-134.YANG Dong-hui, GU Hai-lun, YI Ting-hua, et al. Research advances on diagnosis and evaluation of longitudinal restraint performance of stiffening girders for long-span suspension bridges[J]. China Journal of Highway and Transport, 2025, 38(11): 112-134. [9] SUN J Z, YANG D H, YI T H, et al. Dynamic prediction of the remaining useful life of bridge bearings jointly driven by monitoring and inspection data[J]. Journal of Bridge Engineering, 2026, 31(3): 04025108. doi: 10.1061/JBENF2.BEENG-7650 [10] GU H L, YANG D H, YI T H, et al. Mechanism and characteristics of vehicle-induced girder-end displacement for suspension bridges: A case study[J]. Journal of Bridge Engineering, 2026, 31(3): 05025010. doi: 10.1061/JBENF2.BEENG-7314 [11] GRAZIOTTI F. Seismic bridge response modification due to degradation of viscous dampers performance[D]. San Diego: University of California, 2010. [12] KONSTANTINIDIS D, MAKRIS N, KELLY J M. In-situ condition assessment of seismic fluid dampers: Experimental studies and challenges[J]. Meccanica, 2015, 50(2): 323-340. doi: 10.1007/s11012-014-9882-4 [13] SUN H H, TANG X T, CAI S Y, et al. Fatigue of suspender anchorages under axial and bending loads of suspension bridges[J]. Journal of Constructional Steel Research, 2024, 212: 108252. doi: 10.1016/j.jcsr.2023.108252 [14] WANG H, SHEN R L, BAI L H, et al. Study on the movements and bending stresses of hangers and control measures in self-anchored rail suspension bridges[J]. Engineering Structures, 2023, 275: 115304. doi: 10.1016/j.engstruct.2022.115304 [15] 王涛, 白伦华, 王路, 等. 公铁两用斜拉桥突发断索及列车-桥梁耦合振动特性[J/OL]. 交通运输工程学报, (2025-10-30). https://doi.org/10.19818/j.cnki.1671-1637.2026.013 .WANG Tao, BAI Lun-hua, WANG Lu, et al. Dynamic characteristics of sudden cable fracture and train-bridge coupled vibration of highway-railway cable-stayed bridge[J/OL]. Journal of Traffic and Transportation Engineering, (2025-10-30).https://doi.org/10.19818/j.cnki.1671-1637.2026.013 .[16] LIU J, WANG H, GUO T, et al. Vibration reduction for expansion joints of long-span suspension bridges using frictional dampers[J]. Engineering Structures, 2025, 326: 119579. doi: 10.1016/j.engstruct.2024.119579 [17] 李光玲, 韩万水, 陈笑, 等. 风和随机车流下悬索桥伸缩缝纵向变形[J]. 交通运输工程学报, 2019, 19(5): 21-32. doi: 10.3969/j.issn.1671-1637.2019.05.004LI Guang-ling, HAN Wan-shui, CHEN Xiao, et al. Longitudinal deformation of expansion joint of suspension bridge under wind and random traffic flow [J]. Journal of Traffic and Transportation Engineering, 2019, 19(5): 21-32. doi: 10.3969/j.issn.1671-1637.2019.05.004 [18] 李光玲, 高欢, 韩万水, 等. 基于KPSO算法悬索桥纵向约束体系减振优化[J]. 交通运输工程学报, 2025, 25(2): 270-282. doi: 10.19818/j.cnki.1671-1637.2025.02.017LI Guang-ling, GAO Huan, HAN Wan-shui, et al. Optimization on vibration reduction of longitudinal constraint system in suspension bridges based on KPSO algorithm[J]. Journal of Traffic and Transportation Engineering, 2025, 25(2): 270-282. doi: 10.19818/j.cnki.1671-1637.2025.02.017 [19] 胡尚韬, 李新, 杨孟刚, 等. 黏滞-软钢阻尼器组合系统的协同减震性能研究[J]. 土木工程学报, 2023, 56(4): 51-60.HU Shang-tao, LI Xin, YANG Meng-gang, et al. Research on the coordinated damping performance of the combined viscous-steel damping system[J]. China Civil Engineering Journal, 2023, 56(4): 51-60. [20] SUN Z, SIRINGORINGO D M, CHEN S Z, et al. Cumulative displacement-based detection of damper malfunction in bridges using data-driven isolation forest algorithm[J]. Engineering Failure Analysis, 2023, 143: 106849. doi: 10.1016/j.engfailanal.2022.106849 [21] HUANG G P, HU J H, HUA X G, et al. Analytic solution to longitudinal deformation of suspension bridges under live loads[J]. Journal of Bridge Engineering, 2023, 28(2): 04022147. doi: 10.1061/JBENF2.BEENG-5835 [22] 黄国平, 胡建华, 华旭刚, 等. 随机车流下悬索桥加劲梁纵向运动等效简化模型研究[J]. 地震工程与工程振动, 2025, 45(4): 75-85.HUANG Guo-ping, HU Jian-hua, HUA Xu-gang, et al. Equivalent simplified model for calculating longitudinal movement of the stiffening girder of a suspension bridge under random traffic flow[J]. Earthquake Engineering and Engineering Dynamics, 2025, 45(4): 75-85. [23] DONG Y Q, PAN Y, WANG D L, et al. Transformer-enhanced traffic load simulation for wear evaluation of bridge expansion joint[J]. Structural Control and Health Monitoring, 2024, 31(1): 6631877. [24] WANG Z W, LU X F, ZHANG W M, et al. Deep learning-based reconstruction of missing long-term girder-end displacement data for suspension bridge health monitoring[J]. Computers & Structures, 2023, 284: 107070. [25] MA Y, ZHANG B, HUANG K, et al. Probabilistic prediction and early warning for bridge bearing displacement using sparse variational Gaussian process regression[J]. Structural Safety, 2025, 114: 102564. doi: 10.1016/j.strusafe.2024.102564 [26] 凌琪. 基于随机车流作用的大跨度悬索桥梁端位移响应及减振研究[D]. 成都: 西南交通大学, 2022.LING Qi. Displacement response and vibration reduction of large span suspension bridge based on random traffic flow[D]. Chengdu: Southwest Jiaotong University, 2022. [27] 封周权, 井昊坤, 陈政清, 等. 列车作用下大跨径悬索桥纵向运动响应分析方法对比研究[J]. 土木工程学报, 2024, 57(3): 69-80.FENG Zhou-quan, JING Hao-kun, CHEN Zheng-qing, et al. Comparison of analysis methods for longitudinal motion response of a long-span suspension bridge caused by a running train[J]. China Civil Engineering Journal, 2024, 57(3): 69-80. [28] 沈锐利, 王江浩. 铁路悬索桥在制动力作用下的动力响应分析[J]. 桥梁建设, 2016, 46(6): 24-28.SHEN Rui-li, WANG Jiang-hao. Analysis of dynamic responses of railway suspension bridge under action of train braking force[J]. Bridge Construction, 2016, 46(6): 24-28. [29] JING H K, FENG Z Q, CHEN Z, et al. Analytical solutions for static longitudinal displacements of suspension bridges under a moving vertical concentrated load[J]. Engineering Structures, 2024, 320: 118871. doi: 10.1016/j.engstruct.2024.118871 [30] FENG Z Q, JING H K, ZHANG Y H, et al. Experimental study on train-induced longitudinal movements and control measures for a suspension bridge using a scaled model[J]. Journal of Bridge Engineering, 2025, 30(12): 04025077. doi: 10.1061/JBENF2.BEENG-7688 [31] JING H K, FENG Z Q, CHEN Z, et al. Enhancing longitudinal performance in railway suspension bridges through an integrated cable restrainer system[J]. Structures, 2024, 65: 106769. doi: 10.1016/j.istruc.2024.106769 [32] WU C L, JING H K, FENG Z Q, et al. Control of longitudinal movement response of suspension bridges induced by passing trains using low-exponent fluid viscous dampers[J]. Structures, 2024, 62: 106330. doi: 10.1016/j.istruc.2024.106330 [33] WANG H, SHEN R, WEN W, et al. Investigation of longitudinal movements of girder ends considering various longitudinal non-linear resistances in railway suspension bridges[J]. Journal of Constructional Steel Research, 2024, 214: 108446. doi: 10.1016/j.jcsr.2023.108446 [34] WANG H, SHEN R L, BAI L H, et al. Analytical method for predicting train-induced longitudinal movement at girder ends of suspension bridges with full-scale test validation[J]. Engineering Structures, 2025, 327: 119673. doi: 10.1016/j.engstruct.2025.119673 [35] TICONA MELO L R, MALVEIRO J, RIBEIRO D, et al. Dynamic analysis of the train-bridge system considering the non-linear behaviour of the track-deck interface[J]. Engineering Structures, 2020, 220: 110980. doi: 10.1016/j.engstruct.2020.110980 [36] STOLLWITZER A, BETTINELLI L, FINK J. The longitudinal track-bridge interaction of ballasted track in railway bridges: Experimental determination of dynamic stiffness and damping characteristics[J]. Engineering Structures, 2023, 274: 115115. doi: 10.1016/j.engstruct.2022.115115 [37] 苑仁安, 肖海珠, 汪珍. 大跨度铁路桥梁端位移精细化计算研究[J]. 桥梁建设, 2024, 54(6): 133-139.YUAN Ren-an, XIAO Hai-zhu, WANG Zhen. Research on refined girder-end displacement calculation for long-span railway bridge[J]. Bridge Construction, 2024, 54(6): 133-139. [38] 刘华, 刘兴旺, 陈斌. 千米级铁路悬索桥梁端支座位移长期变化规律分析[J]. 桥梁建设, 2023, 53(3): 48-55.LIU Hua, LIU Xing-wang, CHEN Bin. Analysis of long-term displacements of girder-end bearings of rail-cum-road suspension bridge with main span over 1 000 m[J]. Bridge Construction, 2023, 53(3): 48-55. [39] SUN Z, SANTOS J, CAETANO E, et al. Interpreting cumulative displacement in a suspension bridge with a physics-based characterization of environment and roadway/railway loads[J]. Journal of Civil Structural Health Monitoring, 2023, 13(2): 387-397. [40] CATALLO L, SGAMBI L, SILVESTRI M. General aspects of the structural behavior in the Messina Strait Bridge design[C]∥ISEC. Structural Engineering and Construction Conference. Reston: ISEC, 2003: 23-26. [41] WYATT T A. Secondary stresses in parallel wire suspension cables[J]. Journal of the Structural Division, 1960, 86(7): 37-59. doi: 10.1061/JSDEAG.0000545 [42] KONDOH M, OKUDA M, KAWAGUCHI K, et al. Design method of a hanger system for long-span suspension bridge[J]. Journal of Bridge Engineering, 2001, 6(3): 176-182. doi: 10.1061/(ASCE)1084-0702(2001)6:3(176) -
