Axial compressive performance of round-ended UHPC-filled aluminum alloy tube columns after lateral impact
Article Text (Baidu Translation)
-
摘要: 为探究侧向冲击损伤对圆端形铝合金管约束UHPC（RE-UCFAT）墩柱轴压性能的影响机制，首先开展落锤冲击试验对其施加初始损伤，继而开展轴压试验，系统量化了冲击损伤对构件残余极限承载力及轴向刚度的削弱效应；建立了经参数校准的精细化有限元模型，揭示了冲击损伤演化机理；基于统一理论与有效约束分区思想，提出了适用于RE-UCFAT墩柱的极限承载力计算方法；通过解耦截面实体损伤与整体稳定折减效应，建立了包含能量-轴压交叉耦合的残余承载力预测模型。研究结果表明：圆端形铝合金管对核心UHPC具有良好的约束作用，构件典型破坏模式为弱轴剪切破坏；侧向冲击导致构件承载力与刚度显著退化，且直边损伤造成的性能衰减显著大于曲边损伤；高轴压比下冲击损伤会诱导破坏模式发生转变，直边损伤因引入二阶效应导致构件转为弯剪联合破坏，而曲边损伤则因引入冲切损伤诱发强轴剪切破坏。所建立的数值模型及2类承载力分析模型精度较高，可为该类新型组合墩柱的抗撞设计与评估提供理论依据。Abstract: To investigate the influence mechanism of lateral impact damage on the axial compressive performance of round-ended UHPC-filled aluminum alloy tube (RE-UCFAT) columns, drop-weight impact tests were first conducted to apply initial damage, and axial compression tests were then carried out to systematically quantify the weakening effects of impact damage on the residual ultimate load-carrying capacity and axial stiffness of members. A refined parameter-calibrated finite element model was established to reveal the evolution mechanism of impact damage. Based on the unified theory and the idea of effective confinement zoning, a calculation method for the ultimate load-carrying capacity applicable to RE-UCFAT columns was proposed. By decoupling the cross-sectional solid damage and the overall stability reduction effect, a prediction model for residual load-carrying capacity containing energy-axial compression cross-coupling was established. Research results indicate that the round-ended aluminum alloy tube has a good confinement effect on the core UHPC, and the typical failure mode of the member is weak-axis shear failure. The lateral impact leads to significant degradation of the load-carrying capacity and stiffness of the member, and the performance attenuation caused by straight-edge damage is significantly greater than that caused by curved-edge damage. Under a high axial compression ratio, the impact damage induces a transition in the failure mode. The straight-edge damage causes the member to shift to combined bending-shear failure by introducing the second-order effect, while the curved-edge damage induces strong-axis shear failure by introducing punching shear damage. Validation results show that the established numerical model and the two types of analytical models for load-carrying capacity have high accuracy and can provide a theoretical basis for the impact-resistant design and assessment of this novel type of composite columns.
-
图 4 基准试件和约束试件破坏模态
Figure 4. Failure modes of baseline specimens and constrained specimens
图 8 基准与约束试件荷载-位移曲线
Figure 8. Load-displacement curves of baseline and constrained specimens
图 10 曲边损伤试件荷载-位移曲线
Figure 10. Load-displacement curves of specimens with arc-side damage
图 11 直边损伤试件荷载-位移曲线
Figure 11. Load-displacement curves of specimens with long-side damage
图 15 未冲击试件试验和模拟结果对比
Figure 15. Comparison between experimental and numerical results of unimpacted specimens
图 16 冲击损伤试件极限承载力试验值和模拟值对比
Figure 16. Comparison of experimental and numerical ultimate load-carrying capacities for impact-damaged specimens
图 17 冲击损伤试件的损伤演化和典型破坏模式
Figure 17. Damage evolution and typical failure modes of impact-damaged specimens
图 19 残余承载力预测曲面与散点数据拟合对比
Figure 19. Comparison of theoretical prediction surfaces and scattered data for the residual capacity
表 1 试件主要参数
Table 1. Main parameters of specimens
试件编号 试件类型 n Ek/kJ m/kg 冲击位置 RE-U-B 基准试件 RE-U-C 约束试件 n2-m1-A 冲击损伤试件 0.2 1.1 86 曲边 n2-m1-L 直边 n2-m2-A 1.6 126 曲边 n2-m2-L 直边 n3-m1-A 0.3 1.1 86 曲边 n3-m1-L 直边 n3-m2-A 1.6 126 曲边 n3-m2-L 直边 n4-m1-A 0.4 1.1 86 曲边 n4-m1-L 直边 n4-m2-A 1.6 126 曲边 n4-m2-L 直边 注：试件编号中RE代表圆端形，U代表UHPC，B和C分别代表基准和约束，L和A分别代表直边（平直段）和曲边（圆弧段）。
下载: 导出CSV
表 2 轴压试验主要结果
Table 2. Main results of axial compression tests
试件编号 Ne0.75/kN Δe0.75/mm ky/（kN·mm-1） Nu/kN Δu/mm 破坏模式 RE-U-B 1 080.7 3.17 340.9 1 440.9 4.14 弱轴剪切 RE-U-C 1 019.6 3.72 274.1 1 359.4 7.00 弱轴剪切 n2-m1-A 845.6 2.80 316.3 1 127.5 3.54 弱轴剪切 n2-m2-A 741.3 2.56 289.6 988.4 4.17 弱轴剪切 n2-m1-L 675.7 2.82 299.5 900.9 3.44 弱轴剪切 n2-m2-L 543.5 2.30 236.3 724.6 2.98 弱轴剪切 n3-m1-A 887.0 2.87 309.1 1 182.7 4.25 弱轴剪切 n3-m2-A 792.8 2.80 283.2 1 057.1 4.79 强轴剪切 n3-m1-L 765.7 2.69 284.6 1 020.9 3.49 弱轴剪切 n3-m2-L 676.6 2.73 247.8 902.1 3.60 弱轴剪切+ 整体弯曲 n4-m1-A 710.1 2.97 239.1 946.8 3.43 强轴剪切 n4-m2-A 644.7 3.61 178.6 859.6 4.99 强轴剪切 n4-m1-L 672.1 2.41 278.9 896.1 3.69 弱轴剪切 n4-m2-L 548.3 3.26 168.2 731.0 3.94 弱轴剪切+ 整体弯曲
下载: 导出CSV
表 3 墩柱损伤评估
Table 3. Damage level assessment of columns
损伤指数 （0，0.2] （0.2，0.5] （0.5，0.8] （0.8，1.0] 损伤级别 轻微 中度 重度 损坏
下载: 导出CSV
表 4 试验、模拟与计算结果对比
Table 4. Comparison of experimental and numerical results with calculated results
试件编号 Nu，test/kN Nu，FEM/kN Nu，c1/kN Nu，c2/kN {δFEM，δc1，δc2}/% RE-U-B 1 440.9 1 495.4 1 546.5 1 436.0 {3.78，7.33，-0.34} RE-U-C 1 359.4 1 371.7 1 434.4 1 308.2 {0.90，5.52，-3.77} RE-U-B-180×70 1 848.3 1 879.8 1 740.5 {—，-1.68，6.19} RE-U-C-180×70 1 659.1 1 751.4 1 592.8 {—，-5.27，4.16} RE-U-B-280×100 2 181.8 2 262.2 2 002.9 {—，-3.56，8.93} RE-U-C-280×100 2 006.2 2 128.8 1 854.1 {—，-5.76，8.20}
下载: 导出CSV
-
[1] 赖大德, 陈奕鹏, 廖飞宇, 等. 超高性能混凝土(UHPC)包覆钢管混凝土叠合柱抗侧向冲击试验研究[J]. 工业建筑, 2024, 54(11): 129-135.LAI Da-de, CHEN Yi-peng, LIAO Fei-yu, et al. Experimental research on the behavior of UHPC-encased CFST composite columns subjected to lateral impact loading[J]. Industrial Construction, 2024, 54(11): 129-135. [2] 孔文渊, 邢智权, 陈力波, 等. 外包UHPC加固长期荷载作用下CFST墩柱轴压力学性能[J/OL]. 交通运输工程学报, 2025, https://link.cnki.net/urlid/61.1369.u.20250910.1716.003 .KONG Wen-yuan, XING Zhi-quan, CHEN Li-bo, et al. Axial compressive behavior of CFST pier strengthened with UHPC under long-term load[J/OL]. Journal of Traffic and Transportation Engineering, 2025,https://link.cnki.net/urlid/61.1369.u.20250910.1716.003 .[3] 杨晓强, 张远, 朱利国, 等. 高性能钢管混凝土叠合构件抗侧向冲击性能[J]. 交通运输工程学报, 2025, 25(5): 399-413. doi: 10.19818/j.cnki.1671-1637.2025.05.026YANG Xiao-qiang, ZHANG Yuan, ZHU Li-guo, et al. Lateral impact behavior of high-performance concrete-filled steel tubular composite structural members[J]. Journal of Traffic and Transportation Engineering, 2025, 25(5): 399-413. doi: 10.19818/j.cnki.1671-1637.2025.05.026 [4] 邢智权, 张威威, 聂仁杰, 等. 冲击荷载作用下高强钢筋-UHPFRC梁动力响应研究[J]. 土木工程学报, 2025, 58(5): 27-40.XING Zhi-quan, ZHANG Wei-wei, NIE Ren-jie, et al. Study on the dynamic response of high-strength reinforced UH-PFRC beams under impact loading[J]. China Civil Engineering Journal, 2025, 58(5): 27-40. [5] 罗霞, 余昕烨, 韦建刚, 等. 钢管约束超高性能混凝土加固RC墩柱抗震性能[J]. 交通运输工程学报, 2025, 25(5): 234-249.LUO Xia, YU Xin-ye, WEI Jian-gang, et al. Seismic performance of RC columns strengthened by steel tube-confined ultra-high performance concrete[J]. Journal of Traffic and Transportation Engineering, 2025, 25(5): 234-249. [6] 钱政鑫, 罗霞, 韦建刚. 钢管约束超高性能混凝土加固RC短柱轴压试验研究[J]. 建筑结构学报, 2025, 46(增1): 100-109.QIAN Zheng-xin, LUO Xia, WEI Jian-gang. Study on axial compression performance of UHPC strengthened RC short columns restrained with steel tube[J]. Journal of Building Structures, 2025, 46(S1): 100-109. [7] 韦建刚, 应浩东, 杨艳, 等. 方钢管约束钢筋UHPC短柱抗震性能研究[J/OL]. 土木工程学报, 2025, https://doi.org/10.15951/j.tmgcxb.25080513 .WEI Jian-gang, YING Hao-dong, YANG Yan, et al. Study on seismic behavior of UHPC short columns confined by square steel tubes[J/OL]. China Civil Engineering Journal, 2025,https://doi.org/10.15951/j.tmgcxb.25080513 .[8] 王景玄, 刘芳玲, 李博文. 铝合金管(混凝土)构件力学性能研究进展[J]. 建筑科学与工程学报, 2025, 42(5): 1-14.WANG Jing-xuan, LIU Fang-ling, LI Bo-wen. Research progress on mechanical properties of aluminum alloy tube (concrete) members[J]. Journal of Architecture and Civil Engineering, 2025, 42(5): 1-14. [9] 王景玄, 刘芳玲, 王文达. 铝合金管约束钢筋混凝土柱轴压性能研究[J]. 建筑结构学报, 2025, 46(4): 210-222.WANG Jing-xuan, LIU Fang-ling, WANG Wen-da. Study on axial compressive behavior of aluminum alloy tube confined reinforced concrete[J]. Journal of Building Structures, 2025, 46(4): 210-222. [10] 曾翔, 吴晚博, 霍静思, 等. 圆铝合金管混凝土短柱轴心受压承载力研究[J]. 工程力学, 2021, 38(2): 52-60.ZENG Xiang, WU Wan-bo, HUO Jing-si, et al. The axial strength of concrete-filled aluminum alloy circular tubular stub columns[J]. Engineering Mechanics, 2021, 38(2): 52-60. [11] YAN X F, LIN S Q, ZHAO Y G. Behaviour and confinement mechanism of circular concrete-filled aluminum alloy tubular stub columns under axial compression[J]. Marine Structures, 2024, 95: 103600. doi: 10.1016/j.marstruc.2024.103600 [12] JIANG M Y, SHU Q J, LIU P X, et al. Testing and numerical simulation of concrete-filled 6061-T6 aluminum tubular stub columns[J]. Structures, 2024, DOI: 10.1016/j.istruc.2024.105855. [13] YAN X F, HE M N, HAO J P, et al. Theoretical model of circular concrete-filled aluminum alloy tubular short columns under axial compression[J]. Engineering Structures, 2024, 303: 117549. doi: 10.1016/j.engstruct.2024.117549 [14] HE Z Y, DENG Z H, HU S W, et al. Axial compression performance of coral concrete-filled aluminum alloy tube (CCFAT) circular short columns[J]. Engineering Structures, 2024, 303: 117552. doi: 10.1016/j.engstruct.2024.117552 [15] REN Z G, WANG D D, LI P P. Axial compressive behaviour and confinement effect of round-ended rectangular CFST with different central angles[J]. Composite Structures, 2022, 285: 115193. doi: 10.1016/j.compstruct.2022.115193 [16] ZHAO H, ZHANG W H, WANG R, et al. Axial compression behaviour of round-ended recycled aggregate concrete-filled steel tube stub columns (RE-RACFST): Experiment, numerical modeling and design[J]. Engineering Structures, 2023, 276: 115376. doi: 10.1016/j.engstruct.2022.115376 [17] WANG Z B, ZHUO X R, TAN E L, et al. Axial partial compressive behavior of round-ended concrete-filled steel tubular columns[J]. Journal of Constructional Steel Research, 2024, 220: 108818. doi: 10.1016/j.jcsr.2024.108818 [18] WANG R, LI X, ZHAO H, et al. Eccentric compression performance of round-ended CFST slender columns with different aspect ratios[J]. Journal of Constructional Steel Research, 2023, 211: 108198. doi: 10.1016/j.jcsr.2023.108198 [19] LI X, WANG R, ZHAO H, et al. Bond behaviour of round-ended recycled aggregate concrete filled steel tube (RE-RACFST) columns[J]. Journal of Constructional Steel Research, 2023, 201: 107700. doi: 10.1016/j.jcsr.2022.107700 [20] ZHAO H, MEI S Q, WANG R, et al. Performance of round-ended CFST columns under combined actions of eccentric compression and impact loads[J]. Engineering Structures, 2024, 301: 117328. doi: 10.1016/j.engstruct.2023.117328 [21] ZHAO H, WANG Y H, LI S Y, et al. Post-impact performance of round-ended CFST columns: Tests, numerical analysis and design [J]. Structures, 2024, 70: 107886. doi: 10.1016/j.istruc.2024.107886 [22] ZHAO H, WANG Z H, ZHANG W H, et al. Performance of round-ended recycled aggregate CFST stub columns after fire exposure[J]. Journal of Constructional Steel Research, 2024, 212: 108311. doi: 10.1016/j.jcsr.2023.108311 [23] FAN W, LIU B, CONSOLAZIO G R. Residual capacity of axially loaded circular RC columns after lateral low-velocity impact[J]. Journal of Structural Engineering, 2019, 145(6): 04019039. doi: 10.1061/(ASCE)ST.1943-541X.0002324 [24] XU S C, WU P T, WU C Q. Calibration of KCC concrete model for UHPC against low-velocity impact[J]. International Journal of Impact Engineering, 2020, 144: 103648. doi: 10.1016/j.ijimpeng.2020.103648 [25] ZHOU F, SU Q, CHENG Y H, et al. A novel dynamic constitutive model for UHPC under projectile impact[J]. Engineering Structures, 2023, 280: 115711. doi: 10.1016/j.engstruct.2023.115711 [26] WEI J, LI W, LIU J, et al. Effect of stirrup ratio on response of ultra-high performance concrete beams subjected to low-velocity impact loadings[J]. Journal of Building Engineering, 2024, 92: 109799. doi: 10.1016/j.jobe.2024.109799 [27] SU Q, WU H, POH L H, et al. Dynamic behavior of UHPC-FST under close-in explosions with large charge weight[J]. Engineering Structures, 2023, 277: 115475. doi: 10.1016/j.engstruct.2022.115475 [28] SU Q, WU H, FANG Q. Calibration of KCC model for UHPC under impact and blast loadings[J]. Cement and Concrete Composites, 2022, 127: 104401. doi: 10.1016/j.cemconcomp.2021.104401 [29] WU H, REN G M, FANG Q, et al. Response of ultra-high performance cementitious composites filled steel tube (UHPCC-FST) subjected to low-velocity impact[J]. Thin-walled Structures, 2019, 144: 106341. doi: 10.1016/j.tws.2019.106341 [30] GOU B L, WANG X L, WANG R H, et al. Experimental and numerical studies of impact loading on single-layer reticulated shells with aluminum alloy gusset joints[J]. Engineering Structures, 2024, 302: 117403. doi: 10.1016/j.engstruct.2023.117403 [31] XU W G, ZHANG J G, YAN Q F, et al. Impact performance of assembled aluminum alloy-concrete-carbon steel double-skin tubular column[J]. Ocean Engineering, 2026, 348: 124104. doi: 10.1016/j.oceaneng.2025.124104 [32] PATEL V I, LIANG Q Q, HADI M N S. Numerical simulations of circular high strength concrete-filled aluminum tubular short columns incorporating new concrete confinement model[J]. Thin-walled Structures, 2020, 147: 106492. doi: 10.1016/j.tws.2019.106492 -
图(19) / 表(4)
